Connection Terminal 1,5-16mm², f 10M
Pricing
Request a quote
We reply within 24 hours
Overview
Eaton Connection Terminal 1,5-16mm², f 10M (part number AKU16/10) is listed under Electrical Components / Terminal Blocks. Sales unit: pcs; Package quantity: 100 pcs; Eaton catalogue number: 107191; Depth: 12 mm; Height: 25 mm; Width: 23 mm.
Technical Specifications
- Manufacturer part number (MPN)
- AKU16/10
- EAN / GTIN
- 4015081069545
- Sales unit
- pcs
- Package quantity
- 100 pcs
- Eaton catalogue number
- 107191
- Depth
- 12 mm
- Height
- 25 mm
- Width
- 23 mm
- Weight
- 0.021 kg
- Compliances
- UL CSA09 (refer to approbation report); RoHS conform
- Certifications
- UL (File No. E307559); IEC 60439-1; CSA-C22.2 No. 14; UL508A; CSA (File No. 236217); CE marking; North America (UL listed, CSA certified); UL (Category Control Number NMTR2, NMTR8); CSA (Class No. 3211-37)
- Functions
- Connections; Current limiting circuit breaker, refer to approbation report; Universal conductor connection terminal
- Special features
- With integrated retaining spring, open terminal chamber and captive terminal screw
- Suitable for
- Strip conductor connection; Flat rail; Round conductor connection; Sector conductor connection
- Used with
- All 10 mm thick flat busbars; Feeder circuits; Connection; Compact system; 60 mm system; 185 mm system
- Type
- 185 mm system 60 mm system Compact system Connection
- Rated operation current (Ie)
- 180 A
- Rated operational current
- 180 A
- Rated operational current (Ie) - max
- 180 A
- Voltage rating (UL CSA 13)
- Max. 600 V AC
- Busbar thickness - max
- 10 mm
- Busbar thickness - min
- 10 mm
- Conductor cross section - max
- 16 mm²
- Degree of protection
- UL508A; CSA-C22.2 No. 14; IEC 60439-1; CE marking; Feeder circuits
- Terminal capacity (conductor)
- AWG 14 - AWG 6; 1.5 mm² - 16 mm²; 6 mm x 0.5 mm (8x)
- Terminal contact area
- 7.5 mm x 7.5 mm
- Width clamp
- 11.5 mm
- Max. conductor cross section
- 16 mm²
- Busbar thickness
- 10 mm
- Suitable for strip conductor connection
- Yes
- Suitable for round conductor connection
- Yes
- Suitable for sector conductor connection
- Yes
- Max. rated operation current Ie
- 180 A
- Country of origin
- Germany
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 4015081069545
- SAP 1200607343
- Code 82995623
Product Documentation
