Eaton PLSM-OV56/2 Miniature Circuit Breaker — 2P, OV, 56 A, 10 kA

Eaton PLSM-OV56/2 miniature circuit breaker (MCB) from the xPole PLSM range. 2-pole, rated current In = 56 A, thermomagnetic overload and short-circuit release (Eaton 'OV' overload-protection designation). Rated breaking capacity Icn = 10 kA to IEC 60898-1; rated operational voltage Ue 230/400 V AC. DIN-rail (35 mm) modular device for overload and short-circuit protection of cables and equipment. Conforms to IEC 60898-1. Eaton type PLSM-OV56/2, EAN 4015082649760, Eaton/SAP material 1000026464, catalogue code 8501246.

Manufacturer

Eaton

Product family

xPole PLSM

Type designation

PLSM-OV56/2

Manufacturer part number (MPN)

PLSM-OV56/2

EAN / GTIN

4015082649760

Eaton / SAP material no.

1000026464

Poles

2P

Release

thermomagnetic (overload + short-circuit)

Rated current In

56 A

Rated breaking capacity Icn

10 kA

Rated operational voltage Ue

230/400 V AC

Mounting

DIN rail (35 mm)

Standard

IEC 60898-1

HS code

8536.20

Sales unit

pcs

Eaton catalogue number

264976

Depth

80 mm

Height

72 mm

Width

35.2 mm

Weight

0.24 kg

Compliances

RoHS conform

Current limiting class

3

Features

Additional equipment possible

Special features

Ambient temperature hint: a 1 °C increase results in a 0.5% linear reduction of current carrying capacity

Used with

Miniature circuit breaker; PLSM

Amperage Rating

56 A

Application

Switchgear for residential and commercial applications xPole - Switchgear for residential and commercial applications

Number of poles

Two-pole

Number of poles (protected)

2

Number of poles (total)

2

Release characteristic

Other

Type

Miniature circuit breaker PLSM

Ambient operating temperature - max

75 °C

Ambient operating temperature - min

-25 °C

Heat dissipation capacity

0 W

Heat dissipation per pole, current-dependent

0 W

Rated operational current for specified heat dissipation (In)

56 A

Static heat dissipation, non-current-dependent

0 W

Frequency rating - max

60 Hz

Frequency rating - min

50 Hz

Overvoltage category

III

Pollution degree

2

Rated impulse withstand voltage (Uimp)

4 kV

Rated insulation voltage (Ui)

440 V

Rated operational voltage (Ue) - max

400 V

Rated short-circuit breaking capacity (IEC/EN 60898-1) - Icn at 230 V

10 kA

Rated short-circuit breaking capacity (IEC/EN 60898-1)- Icn at 400 V

10 kA

Voltage type

AC

Built-in depth

70.5 mm

Connectable conductor cross section (multi-wired) - max

25 mm²

Connectable conductor cross section (multi-wired) - min

1 mm²

Connectable conductor cross section (solid-core) - max

25 mm²

Connectable conductor cross section (solid-core) - min

1 mm²

Degree of protection

IP20

Width in number of modular spacings

2

Standard

IEC 60898-1

HS Code

8536.20
