Eaton AZ-4-D100 Miniature Circuit Breaker — 4P, Type D, 100 A, up to 25 kA
Pricing
Request a quote
We reply within 24 hours
Product Description
Eaton AZ-4-D100 miniature circuit breaker (MCB) from the xEffect AZ range. 4-pole, rated current In = 100 A, Type D tripping characteristic. Rated ultimate short-circuit breaking capacity Icu up to 25 kA to IEC/EN 60947-2; rated operational voltage Ue 230/400 V AC. DIN-rail (35 mm) modular device for overload and short-circuit protection of cables and equipment. Conforms to IEC/EN 60947-2. Eaton type AZ-4-D100, EAN 4015081710041, Eaton/SAP material 1200617599, catalogue code 83014547.
Technical Specifications
- Manufacturer
- Eaton
- Product family
- xEffect AZ
- Type designation
- AZ-4-D100
- Manufacturer part number (MPN)
- AZ-4-D100
- EAN / GTIN
- 4015081710041
- Eaton / SAP material no.
- 1200617599
- Poles
- 4P
- Tripping characteristic
- Type D
- Rated current In
- 100 A
- Rated ultimate breaking capacity Icu
- up to 25 kA
- Rated operational voltage Ue
- 230/400 V AC
- Mounting
- DIN rail (35 mm)
- Standard
- IEC/EN 60947-2
- HS code
- 8536.20
- Sales unit
- pcs
- Eaton catalogue number
- 174548
- Depth
- 75 mm
- Height
- 90 mm
- Width
- 108 mm
- Weight
- 0.922 kg
- Compliances
- RoHS conform
- Certifications
- EN45545-2; IEC 61373
- Current limiting class
- 3
- Features
- Additional equipment possible
- Special features
- Ambient temperature hint: a 1 °C increase results in a 0.5% linear reduction of current carrying capacity
- Used with
- AZ; Miniature circuit breaker
- Amperage Rating
- 100 A
- Application
- Switchgear for industrial and advanced commercial applications xEffect - Switchgear for industrial and advanced commercial applications
- Number of poles
- Four-pole
- Number of poles (protected)
- 4
- Number of poles (total)
- 4
- Release characteristic
- D
- Type
- AZ Miniature circuit breaker
- Ambient operating temperature - max
- 55 °C
- Ambient operating temperature - min
- -25 °C
- Equipment heat dissipation, current-dependent
- 36.4 W
- Heat dissipation capacity
- 0 W
- Heat dissipation per pole, current-dependent
- 9.1 W
- Rated operational current for specified heat dissipation (In)
- 100 A
- Static heat dissipation, non-current-dependent
- 0 W
- Frequency rating - max
- 60 Hz
- Frequency rating - min
- 50 Hz
- Overvoltage category
- III
- Pollution degree
- 2
- Rated impulse withstand voltage (Uimp)
- 4 kV
- Rated insulation voltage (Ui)
- 440 V
- Rated operational voltage (Ue) - max
- 400 V
- Rated short-circuit breaking capacity (IEC 60947-2)- Icu at 230 V
- 15 kA
- Rated short-circuit breaking capacity (IEC 60947-2)- Icu at 400 V
- 15 kA
- Rated switching capacity (IEC/EN 60947-2)
- 15 kA
- Voltage type
- AC
- Built-in depth
- 75 mm
- Connectable conductor cross section (multi-wired) - max
- 50 mm²
- Connectable conductor cross section (multi-wired) - min
- 2.5 mm²
- Connectable conductor cross section (solid-core) - max
- 50 mm²
- Connectable conductor cross section (solid-core) - min
- 2.5 mm²
- Degree of protection
- IP20
- Width in number of modular spacings
- 6
Standards & Compliance
- Standard
- IEC/EN 60947-2
- HS Code
- 8536.20
Cross References
- EAN 4015081710041
- SAP 1200617599
- Code 83014547
