Eaton T0-1-15431/XZ Hand-0-Auto Switch 1-Pole 20 A AC-1
Pricing
Request a quote
We reply within 24 hours
Product Description
Eaton T0-1-15431/XZ is a single-pole Hand-0-Auto control switch rated 20 A AC-1 with a toggle actuator and three switch positions (with 0-off position). Rated operating voltage up to 690 V AC, IP00 front-side protection, rear mounting. Catalogue number 005738. Dimensions 48 x 48 x 48 mm, 0.07 kg.
Technical Specifications
- Manufacturer part number (MPN)
- T0-1-15431/XZ
- EAN / GTIN
- 4015080057383
- Sales unit
- pcs
- Eaton catalogue number
- 005738
- Depth
- 48 mm
- Height
- 48 mm
- Width
- 48 mm
- Weight
- 0.07 kg
- Certifications
- CE
- Actuator type
- Toggle
- Number of switch positions
- 2
- Ambient operating temperature - max
- 50 °C
- Ambient operating temperature - min
- -25 °C
- Ambient operating temperature (enclosed) - max
- 40 °C
- Ambient operating temperature (enclosed) - min
- -25 °C
- Climatic proofing
- Damp heat, cyclic, to IEC 60068-2-30; Damp heat, constant, to IEC 60068-2-78
- Control circuit reliability
- 1 failure per 100,000 switching operations statistically determined, at 24 V DC, 10 mA)
- Number of contacts
- 2
- Rated operating voltage (Ue) at AC - max
- 690 V
- Rated uninterrupted current (Iu)
- 20 A
- Fitted with
- 0 (off) position
- Number of poles
- Single-pole
- Degree of protection (front side)
- IP00; NEMA Other
- Mounting method
- Rear mounting
- Mounting position
- As required
- Number of contact units
- 1
- Overvoltage category
- III
- Pollution degree
- 3
- Suitable for
- Intermediate mounting; Ground mounting; Front mounting
- Switching angle
- 45 °
- Type
- Control switch
- Short-circuit protection rating
- 20 A gG/gL, Fuse, Contacts
- Type of switch
- Reverser
- Max. rated operation voltage Ue AC
- 690 V
- Rated permanent current Iu
- 20 A
- With zero (off) position
- Yes
- With retraction in 0-position
- No
- Device construction
- Built-in device
- Suitable for floor mounting
- Yes
- Suitable for front mounting
- Yes
- Suitable for distribution board installation
- No
- Suitable for intermediate mounting
- Yes
- Complete device in housing
- No
- Type of control element
- Wing knob
- Front shield size
- 48x48 mm
- Degree of protection (IP), front side
- IP00
- Country of origin
- United Kingdom
Standards & Compliance
- HS Code
- 8536.50
Cross References
- EAN 4015080057383
- SAP 1000056815
- Code 8541381
