Danfoss VGS Control Valve Body DN 25 PN 25 Kvs 6.3 m³/h (2-Way threaded)

Danfoss VGS two-way threaded seat (globe) control valve body, OEM order code 065B0790. Nominal size DN 25, pressure class PN 25, flow coefficient Kvs 6.3 m³/h. The VGS is the valve-body element of a Danfoss steam control-valve assembly: it pairs with a matched electric AMV / AME (or self-acting) actuator to form a temperature, pressure or flow controller. Red bronze, mat. 2.1096.1 (RG5) body with stainless-steel, mat. 1.4122 cone and stainless-steel, mat. 1.4571 seat, approx. linear flow characteristic, 5 mm stroke, spindle normally open, pressure relief. Rated for steam at 2 °C to 200 °C, maximum differential pressure 10 bar. Connection G 1 1/4 A (ISO 228/1). OEM P/N 065B0790. Data quoted verbatim from store.danfoss.com (code 065B0790). 2.1096.1 (RG5); cone Stainless steel, mat. 1.4122; seat Stainless steel, mat. 1.4571; Standard size: DN 25; Thread: ISO 228/1; Pressure rating: PN 25 (25 bar); max differential pressure 10 bar; Temperature range: 2 °C to 200 °C; Approval: CE; Approvals: CE; HS code: 8481.80. Deployed in process, utility and marine piping loops for on-off shutoff, control, safety relief or diversion service. No. No. No.

Brand

Danfoss

Part number

065B0790

Type

VGS

Product group

Motorized control valves

Application

Steam

Function

Control valve

Valve size

DN 25

Pressure class

PN 25

Nominal pressure

25 bar

PN alternative (VSP)

16

Kvs value

6.3 m³/h

Connection type

External Thread

Connection size

G 1 1/4 A

Connection standard

ISO 228/1

Number of ports

2

Flow characteristic

Approx. linear

Cavitation factor

0.6

Spindle position

Normally open

Stroke

5 mm

Diameter

25 mm

Differential pressure (max)

10 bar

Media temperature

2 °C to 200 °C

Permissible media

Steam

Medium alternative

Circulation water

Media pH range

7 to 10

Leakage through port (max)

0.05 % Kvs

Mounting version

Free

Valve body material

Red bronze, mat. No. 2.1096.1 (RG5)

Valve cone material

Stainless steel, mat. No. 1.4122

Valve seat material

Stainless steel, mat. No. 1.4571

Net weight

1.584 Kilogram

Gross weight

1.584 Kilogram

Volume

1.365 Liter

EAN

5702421543726

SCIP dossier no.

65895f52-3e32-45db-8318-8d3e5b5f455b

HS code

8481.80 (taps, cocks, valves for pipes)

Size / Series

DN 25

Material

Red bronze, mat. No. 2.1096.1 (RG5); cone Stainless steel, mat. No. 1.4122; seat Stainless steel, mat. No. 1.4571

Thread Standard

ISO 228/1

Pressure Rating

PN 25 (25 bar); max differential pressure 10 bar

Temperature Range

2 °C to 200 °C

Classification / Approval

CE

HS Code

8481.80
