Danfoss TE 55 Orifice Assembly No. 9B (ORF) — Thermostatic Expansion Valve Nozzle
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss TE 55 orifice assembly No. 9B (type ORF), OEM order code 067G2705. The orifice (nozzle) is the interchangeable metering element that sets the throttling capacity of the TE 55 / TQ 55 thermostatic expansion valve; it seats in the valve body (067G4001-4004) and is sized by orifice number to the system refrigerating capacity. Balanced port for stable regulation across load. Rated capacities per refrigerant are listed below (Range N unless noted). Compatible with R134a, R22, R404A/R507A, R407A, R407C, R407F, R448A, R449A, R452A, R513A. Data quoted verbatim from store.danfoss.com (code 067G2705).
Technical Specifications
- Brand
- Danfoss
- Part number
- 067G2705
- Type
- ORF (orifice assembly / interchangeable nozzle)
- Used for
- TE 55 / TQ 55 thermostatic expansion valves
- Orifice size (number)
- 9B
- Balanced port
- Yes
- Refrigerant compatibility
- R134a, R22, R404A/R507A, R407A, R407C, R407F, R448A, R449A, R452A, R513A
- Rated capacity R134a (Range N)
- 74 kW / 21 TR
- Rated capacity R22 (Range N)
- 113 kW / 32 TR
- Rated capacity R407C (Range N)
- 109 kW / 31 TR
- Net weight
- 0.25 kg
- Gross weight
- 0.282 kg
- Packing
- 8 pc per multi-pack
- EAN
- 5702428434164
- Approvals
- EAC, LLC CDC TYSK
- HS code
- 8481.90 (valve parts)
- Product group
- Expansion valves
- Approval
- EAC
- Balanced port [Yes/No]
- Yes
- China RoHS compliance
- Out of scope
- EU RoHS compliance
- Yes with exemptions
- EU RoHS exemption clause
- 6(a)
- Orifice size
- 9B
- Rated cap. cond. Range N [IMP]
- tcond=100 °F
- Rated cap. cond. Range N [SI]
- tconc=38 °C
- Rated cap. R134a, Range N [kW]
- 74 kW
- Rated cap. R134a, Range N [TR]
- 21 TR
- Rated cap. R22, Range B [kW]
- 66.2 kW
- Rated cap. R22, Range B [TR]
- 18.8 TR
- Rated cap. R22, Range N [kW]
- 113 kW
- Rated cap. R22, Range N [TR]
- 32 TR
- Rated cap. R404A, Range B [kW]
- 43.2 kW
- Rated cap. R404A, Range B [TR]
- 12.3 TR
- Rated cap. R404A, Range N [kW]
- 84 kW
- Rated cap. R404A, Range N [TR]
- 24 TR
- Rated cap. R407A, Range N [kW]
- 109 kW
- Rated cap. R407A, Range N [TR]
- 31 TR
- Rated cap. R407C, Range N [kW]
- 109 kW
- Rated cap. R407C, Range N [TR]
- 31 TR
- Rated cap. R407F, Range N [kW]
- 123 kW
- Rated cap. R407F, Range N [TR]
- 35 TR
- Rated cap. R507, Range B [kW]
- 43.2 kW
- Rated cap. R507, Range B [TR]
- 12.3 TR
- Rated cap. R507, Range N [kW]
- 84 kW
- Rated cap. R507, Range N [TR]
- 24 TR
- REACH Candidate List substances
- Lead (CAS no. 7439-92-1)
- Refrigerants
- R134a
- Used for product
- TE 55
Standards & Compliance
- Standard
- EN 12284
- Material
- Brass orifice / nozzle assembly (balanced port)
- Classification / Approval
- EAC, LLC CDC TYSK
- HS Code
- 8481.90
Compatibility & Fitment
Fits Danfoss TE 55 / TQ 55 thermostatic expansion valve bodies. Orifice No. 9B. Select the orifice number to match the required refrigerating capacity and refrigerant; pair with the matched power element. Verify the capacity table before ordering.
