Danfoss REG-SA SS 10 hand-operated regulating (manual expansion) valve, 10 mm (3/8 in) angleway, butt weld, stainless steel, 52 bar, Kv 0.15 m3/h (code 148B5017)
Danfoss · HVAC & Refrigeration · Globe Valves
Danfoss REG-SA SS 10 hand-operated regulating valve (manual expansion / throttling valve) for industrial refrigeration, code 148B5017. Stainless-steel body and connections, butt weld, nominal size 10 mm (3/8 in), angleway flow. The REG is a manually adjustable regulating valve used to set a fixed throttling / pressure-drop or to balance refrigerant flow; the SS execution suits stainless pipework and corrosive duties. Maximum working pressure 52 bar (754 psig); media temperature range -60 to 150 C (-76 to 302 F). Flow coefficient Kv 0.15 m3/h (Cv 0.17 gal/min). For R134a, R404A, R407C, R410A, R507A, R717 (ammonia), R744 (CO2) and other HCFC/HFC/HFO refrigerants. PED Article 4, paragraph 3. EAC certified.
Specifications
- Part number
- 148B5017
- HS code
- 8481.80
- Material
- Stainless steel
- Pressure rating
- 52 bar
- Temperature range
- -60 to 150 C
- Standard
- butt weld
- Standard size
- 10 mm
Compatibility
The REG-SA SS 10 sets a manual throttling / regulating differential in industrial refrigeration. Confirm nominal size (10 mm / 3/8 in), connection (butt weld), flow direction (angleway) and body material (stainless steel) before ordering. REG-SA and REG-SB differ in Kv / regulating range.
Approvals
