Danfoss MSV-F2 DN 400 PN 25 flanged manual static balancing valve
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss MSV-F2 DN 400 PN 25 — flanged manual (static) double-regulating balancing valve for the main risers and branches of heating and cooling systems. Presetting the handwheel fixes the valve authority so design flow is distributed correctly across the network; the two built-in test plugs allow differential-pressure and flow measurement for commissioning without extra tappings, and the valve doubles as a shut-off. Kvs 2584.6 m³/h, maximum differential pressure 200 KPa, media temperature -10 °C to 150 °C, Ductile iron (EN-GJS 400-15) body. OEM P/N 003Z1098. EAN 5702421557792. Technical data quoted verbatim from store.danfoss.com (code 003Z1098).
Technical Specifications
- Code number
- 003Z1098
- Type
- MSV-F2
- Product group
- Manual balancing
- Description
- MSV-F2 DN 400 with test plugs PN25, manual balancing valve
- Valve size
- DN 400
- Valve body material
- Ductile iron (EN-GJS 400-15)
- Connection types
- Flange
- Test plugs
- With test plugs
- Setting scale
- Yes
- Shut-off function
- Yes
- Drain function
- No
- Pressure class
- PN 25
- Kvs values [m³/h]
- 2584.6 m³/h
- Differential pressure over the valve [kPa] [Max]
- 200 KPa
- Media temperature [°C] [Min]
- -10 °C
- Media temperature [°C] [Max]
- 150 °C
- Contains batteries
- No
- EU RoHS compliance
- Yes with exemptions
- EU RoHS exemption clause
- 6(c)
- China RoHS compliance
- Out of scope
- REACH Candidate List substances
- Lead (CAS no. 7439-92-1)
- SCIP dossier no.
- 2bc00472-4969-4f4a-bfc8-1c168f67534a
- SCIP dossier product name
- MSV-F2 DN200-DN400
- Net weight
- 900 Kilogram
- Gross weight
- 900 Kilogram
- Volume
- 1536 Liter
- EAN
- 5702421557792
Standards & Compliance
- Material
- Valve body Ductile iron (EN-GJS 400-15)
- Pressure Rating
- PN 25
- Temperature Range
- -10 °C to 150 °C (media)
- Classification / Approval
- CE
- HS Code
- 8481.80
Compatibility & Fitment
MSV-F2 is a static (manual) balancing valve — one per riser or branch. Select by pipe size (DN 400) and network pressure class (PN 25); use the Kvs (2584.6 m³/h) with the branch design flow to set the required presetting, and read the differential pressure across the two test plugs during commissioning. Pair with a Danfoss measuring instrument for flow read-out.
