Danfoss MBS 1700 Pressure Transmitter 0-25 bar 4-20mA G1/4 (060G6103)

Name: Danfoss MBS 1700 Pressure Transmitter 0-25 bar 4-20mA G1/4 (060G6103)
Brand: Danfoss
SKU: CB-DAN-060G6103
Price: 194.99 USD
Availability: InStock

Danfoss · Sensors & Instrumentation · Pressure Transmitters

Danfoss MBS 1700 general-purpose pressure transmitter, range 0-25 bar, 4-20 mA output, G1/4 (EN 837) pressure connection, Pg9 plug (DIN 43650-A / EN 175301-803-A). Enclosure and wetted parts AISI 316L stainless steel. Code no. 060G6103; specification key MBS 1700-2411-1AB04. Supply 9-32 V DC. For industrial and hydraulic pressure measurement.

Specifications

Part number: 060G6103
HS code: 9026.20
Material: AISI 316L stainless steel (enclosure and wetted parts)
Pressure rating: 0-25 bar
Temperature range: -40 to +85 degC
IP rating: IP65

Standards

EN 61326
EN 837
EN 175301-803-A

Approvals
