Danfoss LENO MSV-D static balancing valve, DN 15, PN 20, kVS 3 m³/h, G ½ internal thread

Danfoss LENO MSV-D (003Z7001) — manual (static) presetting double-regulating balancing valve, DN 15, PN 20, for hydronic heating and cooling circuits. The MSV-D combines presetting, shut-off and two test plugs in one body: the presetting scale sets the design kVS so the branch flow is fixed at commissioning, the integral shut-off (leakage Rate A, ISO 5208) isolates the branch, and the test plugs allow differential-pressure/flow measurement. Fully-open kVS 3 m³/h; valve body cW 617N dezincification-resistant brass; medium temperature -20–120 °C; connection G ½ internal thread (Internal thread ISO 228/2). OEM P/N 003Z7001, EAN 5702424617837. Technical data quoted verbatim from store.danfoss.com (code 003Z7001).

Code number

003Z7001

Type

LENO MSV-D

Product group

Manual balancing (static)

Description

Manual (static) presetting double-regulating balancing valve, LENO series

Danfoss description

LENO™ MSV-D valve with internal thread DN 15

Valve size

DN 15

Pressure class

PN 20

kVS value (fully open)

3 m³/h

Connection

G ½ internal thread (Internal thread ISO 228/2)

Max. differential pressure across valve

3 kPa

Presetting scale

Yes

Shut-off function

Yes (leakage Rate A, ISO 5208)

Test plugs

With test plugs

Drain function

No

Medium temperature

-20 – 120 °C

Valve body

CW 617N (dezincification-resistant brass)

EU RoHS compliance

Yes with exemptions (6(c))

REACH Candidate List substance

Lead (CAS no. 7439-92-1)

Net weight

0.59 Kilogram

Gross weight

0.655 Kilogram

Packed volume

1.396 Liter

EAN

5702424617837

HS code

8481.80

Material

Valve body cW 617N dezincification-resistant brass

Thread Standard

ISO 228/2

Pressure Rating

PN 20 (max. differential pressure 3 kPa across valve)

Temperature Range

-20 – 120 °C (medium)

HS Code

8481.80
