Danfoss ICF 20 EVRAT Flexline valve station, 20 mm flange (code 027L4518)
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss ICF 20 EVRAT Flexline valve station (code 027L4518). The ICF valve station combines several refrigeration control functions in one steel housing — for this configuration: Filter (ICFF 15), Solenoid valve (ICFE 20), Manual opening (ICF 15). Connection size 20 mm, connection standard NA (flange) (flange). Maximum working pressure 42 bar (610 psig); media temperature range -40 to +105 C. The ICF Flexline modular concept replaces a string of individually-mounted valves with a single station, reducing weld joints and leak paths. For low- and high-pressure refrigerants in pumped liquid, liquid injection, liquid drain and hot-gas lines, including R717 (ammonia) and R744 (CO2).
Technical Specifications
- Type
- ICF 20 EVRAT Flexline valve station
- Code number
- 027L4518
- Connection size
- 20 mm
- Connection standard
- NA (flange)
- Connection type
- Flange
- Module configuration
- Filter (ICFF 15), Solenoid valve (ICFE 20), Manual opening (ICF 15)
- Body material
- Steel
- Surface coating
- Zn (TLP)
- Maximum working pressure
- 42 bar (610 psig)
- Media temperature range
- -40 to +105 C (-40 to +221 F)
- Weight
- net weight 4.035 kg, gross weight 4.342 kg
- Approvals
- EAC, UL
- EAN
- 5702428884150
- Net weight
- 4.035 Kilogram
- Product group
- Multifunction valves
- Approval
- EAC
- China RoHS compliance
- Yes with exemptions
- China RoHS exemption clause
- 7.1
- Connection Code
- (2060:X:20)
- Connection material
- Steel
- Connection size [in]
- 3/4 in
- Connection size [mm]
- 20 mm
- Direction
- Straightway
- EU RoHS compliance
- Yes with exemptions
- EU RoHS exemption clause
- 6(a)
- Flow direction indicator
- Embossed 1-way arrow
- Fluid Group
- 1
- Max. Working Pressure [bar]
- 42 bar
- Max. Working Pressure [psig]
- 610 psig
- Module 2
- Filter
- Module 2 type
- ICFF 15
- Module 3
- Solenoid valve
- Module 3 type
- ICFE 20
- Module 4
- Manual opening
- Module 4 type
- ICF 15
- PED category
- Art. 4, par. 3
- REACH Candidate List substances
- Lead (CAS no. 7439-92-1)
- Refrigerants
- R134a
- Temperature range [°C] [max]
- 105 °C
- Temperature range [°C] [min]
- -40 °C
- Temperature range [°F] [max]
- 221 °F
- Temperature range [°F] [min]
- -40 °F
- Type code ICF
- ICF-20-4-20XXXXXXXXXXXXXXYXX
- UL approval file name
- REFRIGERANT VALVE 53R0
- UL mark
- Yes
Standards & Compliance
- Size / Series
- 20 mm
- Material
- Steel
- Pressure Rating
- 42 bar
- Temperature Range
- -40 to +105 C
- HS Code
- 8481.80
Compatibility & Fitment
ICF Flexline modular valve station for industrial refrigeration. This code is the factory build ICF 20 EVRAT (Filter (ICFF 15), Solenoid valve (ICFE 20), Manual opening (ICF 15)). The station bolts into a 20 mm line (NA (flange), flange); individual function modules can be serviced without removing the housing from the line. Confirm line size, connection standard, refrigerant and required functions match this configuration before ordering.
