Product Description
Danfoss HVZ 3 PN16 20/4 2-way seated valve with a flat-end connection, for heating and cooling circulation water including glycol mixtures up to 50% at 2-120 °C and up to 16 bar. Kvs 2.5 m³/h through the B-AB port with a logarithmic flow characteristic, DZR brass body and cone, EPDM stuffing-box seal, stainless steel stem. Normally closed A-AB with 5.5 mm stroke. Reference part number 065Z5421.
Technical Specifications
- Code number
- 065Z5421
- EAN
- 5702421526637
- Net weight
- 0.506 Kilogram
- Application
- Heating and cooling
- Application alternative VSP
- Hot water
- China RoHS exemption clause
- 7.3
- Connection size
- G 3/4
- Connection types
- External thread ISO 228/1
- Control ratio
- 50:1
- Description
- HVZ 3 PN16 20/4 2-way seated flat end
- Diameter [mm]
- 20 mm
- EU RoHS compliance
- Yes with exemptions
- Flow characteristic
- Logarithmic
- Function
- Mixing valve
- Kvs value (B-AB) [m³/h]
- 2.50 m³/h
- Kvs values [m³/h]
- 4.00 m³/h
- Leakage through port (B-AB) max. [% Kvs]
- 1.0
- Leakage through port max. [% Kvs]
- 0.05
- Medium alternative
- Glycolic water up to 50%
- Mounting version
- Free
- Number of ports
- 3
- Permissible media
- District heating/cooling circulation water
- PN alternative VSP
- 10
- Pressure nominal [bar]
- 16 bar
- Product group
- Other valves
- Product line
- Hydronic Balancing and Controls
- Product Type
- VZ 3
- Spindle position
- A-AB: Normally closed
- Stroke [mm]
- 5.50 mm
- Stuffing box sealing material
- EPDM
- Valve body material
- DZR brass CuZn36Pb2AS (CW 602N)
- Valve cone material
- DZR brass CuZn36Pb2AS (CW 602N)
- Valve seat material
- DZR brass CuZn36Pb2AS (CW 602N)
- Valve stem material
- Stainless steel
- Closing differential pressure (diverting) [bar]
- 1.0 bar
- Closing differential pressure (mixing) [bar]
- 2.5 bar
- Media pH
- 7 … 10
- Media temperature [°C]
- 2 °C … 120 °C
- Gross weight
- 0.506 Kilogram
- Volume
- 0.638 Liter
- Type
- VZ 3
