Danfoss FIA 20 angleway strainer housing, 20 mm (3/4 in) butt weld EN 10220, 52 bar, steel
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss FIA 20 in-line strainer housing for the SVL Flexline industrial-refrigeration range. Angleway body with 20 mm (3/4 in) butt weld connections to EN 10220. The strainer protects downstream valves, pumps and controls by trapping scale, weld slag and debris carried in the refrigerant. Steel body suits HCFC, non-flammable HFC, R717 (ammonia) and R744 (CO2) systems; maximum working pressure 52 bar (754 psig); media temperature range -60 to 150 C (-76 to 302 F). Housing supplied with cover; the filter insert (µ100/µ150/µ250/µ500 plain or pleated mesh) is ordered separately to suit the required filtration grade and pressure drop.
Technical Specifications
- Type
- Strainer housing, FIA 20
- Code number
- 148B5342
- Series
- SVL Flexline (FIA strainer)
- Product group
- Strainers
- Nominal size
- 20 mm (3/4 in)
- Direction
- Angleway
- Connection
- Butt weld
- Connection standard
- EN 10220
- Equipment
- Cover
- Body material
- Steel
- Maximum working pressure
- 52 bar (754 psig)
- Media temperature range
- -60 to 150 C (-76 to 302 F)
- Kv value (µ100 plain)
- 6.9 m3/h
- Kv value (µ150 plain)
- 7.1 m3/h
- Kv value (µ150 pleated)
- 8.8 m3/h
- Kv value (µ250 plain)
- 7.3 m3/h
- Kv value (µ500 plain)
- 7.7 m3/h
- Applicable media
- HCFC, HFC, R717 (ammonia), R744 (CO2)
- Conformity assessment
- PED Article 4, paragraph 3 (sound engineering practice)
- Approvals
- CE
- Net weight
- 1.267 kg
- EAN
- 5702428472739
Standards & Compliance
- Size / Series
- 20 mm
- Material
- Steel
- Pressure Rating
- 52 bar
- Temperature Range
- -60 to 150 C
- HS Code
- 8421.39
Compatibility & Fitment
Danfoss FIA in-line strainer housing for the SVL Flexline industrial-refrigeration range. Protects downstream valves, pumps and controls by trapping scale and debris. Select by nominal size, body direction (angleway / straightway) and connection (weld standard). The filter insert (mesh grade, plain or pleated) is ordered separately; butt weld, socket weld and different weld standards are separate housing codes and are not interchangeable.
