Danfoss FIA 15 straightway strainer housing, 15 mm (1/2 in) butt weld ASME B 36.10M Schedule 80, 52 bar, steel (code 148B5247)
Danfoss · HVAC & Refrigeration · Filters & Driers
Danfoss FIA 15 strainer (filter) housing for the SVL Flexline industrial-refrigeration range, code 148B5247. The FIA is an in-line strainer that protects downstream valves, pumps and controls by holding a replaceable filter insert in the flow; the housing is common and the filtration fineness is set by the chosen insert (µ100, µ150, µ250 or µ500, plain or pleated). This SKU is the straightway housing in 15 mm (1/2 in) butt weld connections to ASME B 36.10M Schedule 80. Flow coefficient by insert: µ100 2.5 / µ150 2.6 / µ150 pleated 3.3 / µ250 2.7 / µ500 2.8 m3/h. Steel housing rated 52 bar (754 psig) maximum working pressure, media temperature -60 to 150 C (-76 to 302 F). Suits HCFC, non-flammable HFC, R717 (ammonia) and R744 (CO2) systems. Built on the SVL Flexline modular platform — the complete top part is interchangeable across the SVA-S/SVA-L, REG and SCA-X functions; the filter insert is serviced without removing the housing from the line.
Specifications
- Part number
- 148B5247
- HS code
- 8421.39
- Material
- Steel
- Pressure rating
- 52 bar
- Temperature range
- -60 to 150 C
- Standard size
- 15 mm
Compatibility
Danfoss SVL Flexline FIA strainer housing. Select by nominal size (15 mm / 1/2 in), body direction (straightway) and connection standard (ASME B 36.10M Schedule 80 butt weld). The filter insert (fineness µ100 / µ150 / µ250 / µ500, plain or pleated) sets the filtration grade and is ordered separately. Connection preparations (EN 10220 / ASME B 36.10M / ASME B 16.11 / NPT) are not interchangeable — confirm the mating connection. Shares the SVL Flexline platform with SVA-S/SVA-L, REG and SCA-X functions; the complete top part is interchangeable.
Approvals
