Danfoss FIA-140B 125 function module (Top Complete strainer insert) for 140 bar CO2 strainer, SVL Flexline
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss FIA-140B 125 function module (Top Complete), code 148B6935 — the complete top part with stainless-steel filter net that converts an SVL-140B 125 valve body into an inline strainer for 140 bar (2030 psig) industrial R744 (CO2) service. The filter net is mounted directly without extra gaskets for easy servicing. Plain and pleated stainless-steel inserts (150 to 500 micron) are available; sizes 80-100 (3-4 in) can take a magnetic insert. The top part exchanges on an installed body without welding, so a strainer can be re-tasked as a shut-off valve (SVA-140B) and back by swapping the module. Used for products SVL-140B 125. Supplied with 1 gasket.
Technical Specifications
- Type
- FIA-140B 125 function module (Top Complete)
- Code number
- 148B6935
- Series
- SVL-140B Flexline (140 bar CO2)
- Product group
- Strainers / filter driers
- Function
- Converts SVL-140B body to inline strainer
- Equipment
- Top Complete (strainer insert top part)
- Filter net
- Stainless steel, mounted direct (no extra gaskets); plain or pleated inserts 150-500 micron
- Parts included
- 1 gasket; complete top part
- Used for products
- SVL-140B 125
- Maximum working pressure
- 140 bar (2030 psig)
- Media temperature range
- -40 to 150 C (-40 to 302 F)
- Applicable media
- R744 (CO2), sub- and trans-critical
- CE mark
- Yes
- Approvals
- C UL US LISTED, CE, CRN
- Net weight
- 9.35 kg
- Gross weight
- 12.454 kg
- EAN
- 5715162512043
- Approval
- C UL US LISTED
- China RoHS compliance
- Yes
- EU RoHS compliance
- Yes
- Max. Working Pressure [bar]
- 140 bar
- Max. Working Pressure [psig]
- 2030 psig
- REACH Candidate List substances
- No
- Refrigerants
- R744
- Temperature range [°C] [max]
- 150 °C
- Temperature range [°C] [min]
- -40 °C
- Temperature range [°F] [max]
- 302 °F
- Temperature range [°F] [min]
- -40 °F
- Type designation
- Top Complete
- Used for product
- SVL-140B 125
Standards & Compliance
- Material
- Low-temperature steel
- Pressure Rating
- 140 bar
- Temperature Range
- -40 to 150 C
- HS Code
- 8421.99
Compatibility & Fitment
Danfoss FIA-140B strainer function module (spare top part) for the 140 bar CO2 SVL Flexline. Fits the SVL-140B 125 valve body (SVL-140B 125); the module exchanges on an installed body without welding. Order stainless-steel plain, pleated or (sizes 80-100) magnetic inserts separately. The SVA-140B shut-off module fits the same body for stop-valve duty. Not interchangeable with the 52/65 bar SVL family.
