Danfoss flange and gasket set for DSV 2 / SFA 15, FD32 / ND20, 4-piece set (code 148F3040)
Danfoss · HVAC & Refrigeration · Valve Spare Parts
Danfoss safety-valve spare-parts set, code 148F3040: Safety valve spare parts, flanges + gaskets, FD32/ND20, DSV 2 / SFA 15. A genuine OEM flange and gasket set (4 pieces) used to connect a SFA 15 safety relief valve to a DSV 2 change-over / double stop valve, connection size FD32 / ND20. Supplied as a matched multi-pack so the safety valve and change-over valve seal correctly when a safety valve is inspected or replaced. Specifications per Danfoss store code 148F3040.
Specifications
- Part number
- 148F3040
- HS code
- 8481.90
- Material
- Steel flanges/nipples with gaskets
- Pressure rating
- 40 bar g (matched to DSV / safety valve)
- Temperature range
- -50 to 100 C
- Standard size
- FD32 / ND20
Compatibility
Danfoss OEM spare set for the DSV 2 / SFA 15 change-over / safety-valve combination, connection size FD32 / ND20. Order to match the chosen DSV change-over valve and safety-valve connection type.
Standards
Approvals
