Danfoss flange and gasket set for DSV 2 / SFV 20, FD32 / FD25, 4-Piece set
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss safety-valve spare-parts set, code 148F3042: Safety valve spare parts, flanges + gaskets, FD32/FD25, DSV 2 / SFV 20. A genuine OEM flange and gasket set (4 pieces) used to connect a SFV 20 safety relief valve to a DSV 2 change-over / double stop valve, connection size FD32 / FD25. Supplied as a matched multi-pack so the safety valve and change-over valve seal correctly when a safety valve is inspected or replaced. Specifications per Danfoss store code 148F3042.
Technical Specifications
- Type
- Flange and gasket set (safety-valve spare parts)
- Code number
- 148F3042
- For valve combination
- DSV 2 / SFV 20
- Connection size designation
- FD32 / FD25
- Pack quantity
- 4 pieces
- Application
- connects the safety relief valve to the DSV change-over / double stop valve
- Net weight
- 5.167 kg
- Gross weight
- 5.205 kg
- EAN
- 5702428203739
- Product group
- Safety valve spare parts
- Type designation
- Flange and gasket set
- Approval
- EAC
- REACH candidate-list substances
- No
- Used for product comments
- FD32/FD25
- EU RoHS compliance
- Yes
- Compatible with
- DSV 2 / SFV 20
- China RoHS compliance
- Yes
- Used for product
- DSV 2
Standards & Compliance
- Size / Series
- FD32 / FD25
- Material
- Steel flanges/nipples with gaskets
- Pressure Rating
- 40 bar g (matched to DSV / safety valve)
- Temperature Range
- -50 to 100 C
- HS Code
- 8481.90
Compatibility & Fitment
Danfoss OEM spare set for the DSV 2 / SFV 20 change-over / safety-valve combination, connection size FD32 / FD25. Order to match the chosen DSV change-over valve and safety-valve connection type.
