Danfoss MBS 33 Pressure Transmitter - 1/2", 0-6bar 10011804
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss MBS 33 Pressure Transmitter. Push buttons (Plumbing / Heat / Valves for heating and cooling systems). Principal data: connection 1/2", setting range 0-6 bar. Supplied under manufacturer part number 060G1226, EAN 5702423062973, HS code 9026.20, country of origin China.
Technical Specifications
- Product type
- Push buttons
- Product group
- Heat
- Connection
- 1/2"
- Setting range
- 0-6 bar
- Type
- MBS 33
- REACH SVHC substance above 0.1%
- Lead
- Carbon footprint (EPD)
- 1.7732 kg CO2e per pcs
- Country of origin
- China
- Customs tariff code (EU CN)
- 90262020
- HS code
- 9026.20
- Manufacturer part number
- 060G1226
- VVS number
- 475175605
- EAN
- 5702423062973
- Net weight
- 0.187 Kilogram
- + output
- Pin 3
- + supply
- Pin 1
- - common
- Pin 2
- Accuracy, max. [±FS%]
- 0.8 %
- Accuracy, typical [±FS%]
- 0.3 %
- Adj. zero point and span
- No
- Ambient temperature range [°C] [max]
- 85 °C
- Ambient temperature range [°C] [min]
- -40 °C
- Ambient temperature range [°F] [max]
- 185 °F
- Ambient temperature range [°F] [min]
- -40 °F
- Approval
- ATEX
- Approval comments
- ATEX Ex ec IIA T4 Gc
- CE mark
- Yes
- China RoHS compliance
- Out of scope
- Compensated temp. range [°C] [max]
- 80 °C
- Compensated temp. range [°C] [min]
- 0 °C
- Compensated temp. range [°F] [max]
- 176 °F
- Compensated temp. range [°F] [min]
- 32 °F
- EEE category
- 5 small equipment (any external dimension < 50 cm)
- Electrical conn. Male/Female
- Male and Female
- Electrical connection
- Angular connector
- Electrical connection size
- Pg 9
- Electrical connection standard
- EN 175301-803-A
- Enclosure rating IP
- IP65
- EU RoHS compliance
- Yes with exemptions
- EU RoHS exemption clause
- 6(c)
- Flush diaphragm
- No
- High Clipping Level
- 11.5
- In scope of WEEE
- Yes
- International Article Number
- 5702423062973
- Intrinsically safe
- No
- Low Clipping level
- 0
- Medium temperature range [°C] [max]
- 85 °C
- Medium temperature range [°C] [min]
- -40 °C
- Medium temperature range [°F] [max]
- 185 °F
- Medium temperature range [°F] [min]
- -40 °F
- Non-linearity BFSL [±FS%]
- 0.2 %
- Output signal
- Voltage
- Output signal [V] [max]
- 10 V
- Output signal [V] [min]
- 0 V
- Overload pressure max. [bar]
- 20 bar
- Pressure connection HEX [mm]
- 27 mm
- Pressure connection size
- 1/2
- Pressure connection standard
- EN 837
- Pressure connection type
- G
- Pressure Male/Female
- Male
- Pressure range [bar] [max]
- 6 bar
- Pressure range [bar] [min]
- 0 bar
- Pressure range [psi] [max]
- 87 psi
- Pressure range [psi] [min]
- 0 psi
- Pressure reference
- Gauge (relative)
- Pulse-snubber
- No
- REACH Candidate Strip substances
- Lead (CAS no. 7439-92-1)
- Response time max. [ms]
- 4 ms
- Specification key
- MBS 33-1815-A1AB08-0
- Supply current max. [mA]
- 8 mA
- Supply voltage [V] DC [max]
- 32 V
- Supply voltage [V] DC [min]
- 15 V
- UL mark
- Yes
Standards & Compliance
- HS Code
- 9026.20
Cross References
- MPN 060G1226
- EAN 5702423062973
- VVS 475175605
Product Documentation
More from Danfoss
Danfoss
Danfoss TWA-V Thermo Actuator - Closed (NC), 230 V AC
1474055
Danfoss
Danfoss MBT 5252 Sensor - 1/2", 0°C, 100°C, 150mm
10248065
Danfoss
Danfoss CS Pressure Switch - 4-12bar
031E022566
Danfoss
Danfoss Rotalock Valve Set - 1 1/4" Rotalock x 3/4" solder, 1 3/4" Rotalock x 1 1/8" solder
7703009
Danfoss
Danfoss XGE Fan speed controller - 20-55°C, 22-39bar, 7bar, 28bar, 3A, 1, XGE-6C
061H3160
Danfoss
Danfoss Cable Plug 230V - 018F coil type B, 018Z coil type B, 042N coil type B
042N0265
Danfoss
Danfoss FJV 15 Return Flow Thermostat with nipple connection - 20°C, 50°C, 1M³/h
003N5117
Danfoss
Danfoss VM 2 Seat Valve 2-Way - 25, 1 1/4", Nipple, 8M³/h
2550804
Technical guides
- Cross-Referencing Danfoss Refrigeration Components by IMPA and OEM Code
- Danfoss Product Code Decoder — 003Z, 013G, 017B, 023U, 027L, 032F, 060G, 060H, 065B, 065Z, 068Z, 084H, 132F, 148B Series (Complete Reference)
- Danfoss Maneurop MTZ Reciprocating Compressors — Model Range, Voltage Codes and Replacement Guide
Catalogue entry last verified: 2026-09-30. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
