Danfoss
Danfoss ETS Electronic expansion valve - ETS 25
Part number034G4203EAN / GTIN5702428825757HS code8481.80
HVAC & Refrigeration
Expansion Valves
MOQ:1
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss ETS Electronic expansion valve. Electronic expansion valves (Refrigeration technology / Cooling technical components / Expansion valves). Principal data: type designation ETS 25. Supplied under manufacturer part number 034G4203, HS code 8481.80, country of origin Denmark.
Technical Specifications
- Product type
- Electronic expansion valves
- Product group
- Cooling technical components
- Type designation
- ETS 25
- Carbon footprint (EPD)
- 8.5132 kg CO2e per pcs
- Country of origin
- Denmark
- Customs tariff code (EU CN)
- 84818099
- HS code
- 8481.80
- Manufacturer part number
- 034G4203
- EAN
- 5702428825757
- Net weight
- 0.911 Kilogram
- Type
- ETS 25
- Ambient temperature range [°C] [max]
- 60 °C
- Ambient temperature range [°C] [min]
- -40 °C
- Ambient temperature range [°F] [max]
- 140 °F
- Ambient temperature range [°F] [min]
- -40 °F
- Approval
- CE
- Balanced port [Yes/No]
- No
- CE mark
- Yes
- China RoHS compliance
- Yes with exemptions
- China RoHS exemption clause
- 7.3
- Compatible Danfoss controllers
- EKE 1A
- Connection Code
- (3001:X:22); (3002:X:22)
- Connection material
- Copper
- Direction
- Straightway
- Electrical conn. Male/Female
- Male
- Electrical connection
- M12
- Electrical connection size
- 4 pin
- Enclosure rating IP
- IP67
- EU RoHS compliance
- Yes with exemptions
- EU RoHS exemption clause
- 6(c)
- Flow direction
- Bi-flow
- Flow direction indicator
- Embossed 2-way arrow
- Fluid Group
- 2
- Full travel time speed [s] [max]
- 17 s
- Full travel time speed [s] [min]
- 8.5 s
- Inlet connection type
- Solder ODF
- Inlet size [in]
- 7/8 in
- Inlet size [mm]
- 22 mm
- Lubricants compatibility
- MO
- Manual operation option
- AST-G service driver
- Max allowed duty cycle [%]
- 100 %
- Max tot PowerCons CurrDrive[W]
- 1.3 W
- Max tot PowerCons VoltDrive[W]
- 5.5 W
- Max. Working Pressure [bar]
- 45.5 bar
- Max. Working Pressure [psig]
- 660 psig
- MaxOPD [bar]
- 33 bar
- MaxOPD [psi]
- 478.6 psi
- MaxOPD reverse [bar]
- 33 bar
- MaxOPD reverse [psi]
- 478.6 psi
- Motor type
- Bi-polar
- Outlet connection type
- Solder ODF
- Outlet size [in]
- 7/8 in
- Outlet size [mm]
- 22 mm
- PED category
- I
- Phase current (peak) [mA]
- 141 mA
- Phase current (RMS) [mA]
- 100 mA
- Phase inductance [µH]
- 85000 μH
- Rated cap. cond. note
- Full stroke open, normal flow
- Rated cap. conditions [IMP]
- tcond=90 °F
- Rated cap. conditions [SI]
- tcond=32 °C
- Rated cap. R404A/R507A [kW]
- 88 kW
- Rated cap. R404A/R507A [TR]
- 25 TR
- Rated capacity R134a [kW]
- 93 kW
- Rated capacity R134a [TR]
- 27 TR
- Rated capacity R22 [kW]
- 117 kW
- Rated capacity R22 [TR]
- 34 TR
- Rated capacity R407C [kW]
- 129 kW
- Rated capacity R407C [TR]
- 37 TR
- Rated capacity R410A [kW]
- 144 kW
- Rated capacity R410A [TR]
- 41 TR
- REACH Candidate Strip substances
- Lead (CAS no. 7439-92-1)
- Refrigerant temperature [ºC] [max]
- 65 °C
- Refrigerant temperature [ºC] [min]
- -40 °C
- Refrigerant temperature [ºF] [max]
- 150 °F
- Refrigerant temperature [ºF] [min]
- -40 °F
- Refrigerants
- R1234ze(E)
- Resistance [kOhm]
- 0.1 kOhm
- Step mode
- 2-phase full step
- Total steps
- 2625 (full steps)
- UL approved refrigerants
- R134a
- UL mark
- Yes
- Voltage [V] DC [max]
- 13.8 V
- Voltage [V] DC [min]
- 11.5 V
Standards & Compliance
- HS Code
- 8481.80
Cross References
- MPN 034G4203
Product Documentation
Document preview: Manufacturer's declaration
More from Danfoss
Danfoss
Danfoss T 2 Thermostatic expansion valve flare/solder - R455A, Intern, -40-10°C, T 2 R455A
068Z7494
Danfoss
Danfoss Oil Sight Glass
8156019
Danfoss
Danfoss Measuring Nipple set of extenders
003Z3946
Danfoss
Danfoss KP - LP Pressure Switch - 0,2-7,5bar, Auto, KP1
1485853
Danfoss
Danfoss Spare Part Set - 10024102
Danfoss
Danfoss Pressure Switch - 10248373
Danfoss
Danfoss AVQM Flow Limiter - 15, Nipple/nipple, 3/4", 2.5M³/h
4006957
Danfoss
Danfoss KVP Evaporator Pressure Regulator - 18bar, 2.5M³/h, 7/8" solder, KVP 22
5702428411844
Technical guides
- Expansion Valve Finder — Danfoss TE 2 / TE 5 / TE 12 / TE 20 / TE 55, TGE, TUA / TUB / TUBE, T2 / TS2, AKV and ETS Colibri by Refrigerant, Connection and Type
- Cross-Referencing Danfoss Refrigeration Components by IMPA and OEM Code
- Danfoss Product Code Decoder — 003Z, 013G, 017B, 023U, 027L, 032F, 060G, 060H, 065B, 065Z, 068Z, 084H, 132F, 148B Series (Complete Reference)
Catalogue entry last verified: 2026-09-30. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
