Danfoss AV210E 50B Solenoid Valve PTFE - 2", NO (Normally open)
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss AV210E 50B Solenoid Valve PTFE. EV220B solenoid valve (Plumbing / Heat / Valves for heating and cooling systems). Principal data: connection 2", valve position NO (Normally open). Supplied under manufacturer part number 042N4486, EAN 5702423194650, HS code 8481.80, country of origin Italy.
Technical Specifications
- Product type
- EV220B solenoid valve
- Product group
- Heat
- Connection
- 2"
- Valve position
- NO (Normally open)
- Differential pressure
- 0 - 16 bar
- Control
- Piston (angled)
- Connection internal/external
- Internal
- Media temperature
- -30 - 180 °C
- Kv value
- 67
- Housing material
- Stainless steel
- Head diameter
- 110 mm
- Closure
- Against flow
- Ambient temperature max
- 60 °C
- Orifice size
- 50 mm
- Operating pressure max
- 16 bar
- Test pressure
- 24 bar
- REACH SVHC substance above 0.1%
- Lead
- Carbon footprint (EPD)
- 40.9227 kg CO2e per pcs
- Country of origin
- Italy
- Customs tariff code (EU CN)
- 84818079
- HS code
- 8481.80
- Manufacturer part number
- 042N4486
- VVS number
- 470161912
- EAN
- 5702423194650
Standards & Compliance
- HS Code
- 8481.80
Cross References
- MPN 042N4486
- EAN 5702423194650
- VVS 470161912
Product Documentation
More from Danfoss
Danfoss
Danfoss BE240AS Coil - 240 V AC, 11W
018F6177
Danfoss
Danfoss ABNM A5 LOG Thermo Actuator - 10-32, 24V AC
082F1160
Danfoss
Danfoss Pressure Switch - 10082661
Danfoss
Danfoss VRB 2 Seat Valve 2-Way - 25, 1", coupling, 10M³/h
4007152
Danfoss
Danfoss RAVK Sensor Element - 25°C, 65°C, 2M
013U8063
Danfoss
Danfoss EVR Solenoid Valve solder - 45.2bar, 5M³/h, 7/8" solder, 93kW, 70kW, 95kW, R22, R32, R134A, R290, R404A, R407A, R407C, R407F, R410A, R417A, R438A, R448A, R449A, R450A, R452A, R452B, R454A (XL40), R454C (XL20), R455A, R513A, R507, R600, R600A, R1234YF, R1234ZE, EVR 20S
10400625
Danfoss
Danfoss EVR Solenoid Valve solder - 0.27M³/h, 3/8" solder, 5kW, 3.8kW, 5.1kW, R22, R32, R134A, R290, R404A, R407A, R407C, R407F, R410A, R417A, R448A, R449A, R450A, R452A, R452B, R454A (XL40), R454B (XL41), R454C (XL20), R455A, R507, R513A, R600, R600A, R1234YF, R1234ZE, EVR 3S
5702422004189
Danfoss
Danfoss RT 200 Pressure Switch min. Reset - 0,2-6,0bar
706804
Technical guides
- Cross-Referencing Danfoss Refrigeration Components by IMPA and OEM Code
- Danfoss Product Code Decoder — 003Z, 013G, 017B, 023U, 027L, 032F, 060G, 060H, 065B, 065Z, 068Z, 084H, 132F, 148B Series (Complete Reference)
- Danfoss Maneurop MTZ Reciprocating Compressors — Model Range, Voltage Codes and Replacement Guide
Catalogue entry last verified: 2026-09-29. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy 042N4486?
- 042N4486 can be ordered from cballast.com as a Danfoss catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Danfoss product?
- The manufacturer part number is 042N4486.
- What is the HS code for 042N4486?
- The customs tariff (HS) code for 042N4486 is 8481.80.
- Who manufactures 042N4486?
- 042N4486 is a Danfoss product in the HVAC & Refrigeration range.
- Is a datasheet available for 042N4486?
- Yes — the 042N4486 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for 042N4486?
- The minimum order quantity is 1.
- Is 042N4486 available?
- Yes — 042N4486 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
