Danfoss CCMT 10L electric regulating valve, solder ODF 7/8 in / weld 3/4 in
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss CCMT 10L electric regulating valve (code 027H7279), part of the Colibri electrically operated valve range for transcritical and subcritical CO2 (R744) refrigeration. Solder ODF 7/8 in / weld 3/4 in connection; Kv 1.1 m3/h, maximum working pressure 140 bar (2030 psig). Motor-operated for stepless capacity and pressure regulation; the matching actuator drive and controller are ordered separately.
Technical Specifications
- Type
- CCMT 10L electric regulating valve
- Code number
- 027H7279
- Connection type
- solder, ODF
- Solder connection size
- 7/8 in
- Weld connection size
- 3/4 in
- Kv value
- 1.1 m3/h
- Maximum working pressure
- 140 bar (2030 psig)
- Valve operation
- electrically (motor) operated
- Refrigerant
- R744 (CO2)
- Net weight
- 0.672 kg; gross weight: 0.807 kg
- Approvals
- EAC, UL (cURus)
- EAN
- 5715162287071
- Product group
- Press. and temp. regul. valves
- Ambient temperature range [°C] [max]
- 50 °C
- Ambient temperature range [°C] [min]
- -40 °C
- Ambient temperature range [°F] [max]
- 120 °F
- Ambient temperature range [°F] [min]
- -40 °F
- Approval
- EAC
- China RoHS compliance
- Yes
- Connection Code
- (2001:D23:20); (3002:X:22)
- Connection Solder size [in]
- 7/8 in
- Connection standard
- EN10220
- Connection Weld size [in]
- 3/4 in
- Cv value [gal/min]
- 1.28 gal/min
- Diff.press.setting range [bar]
- 90 bar
- Diff.press.setting range [psi]
- 1305 psi
- EU RoHS compliance
- Yes
- Kv value [m³/h]
- 1.1 m³/h
- Max. Working Pressure [bar]
- 140 bar
- Max. Working Pressure [psig]
- 2030 psig
- MaxOPD [bar]
- 90 bar
- MaxOPD [psig]
- 1305 psig
- REACH Candidate List substances
- No
- Refrigerants
- R744
- Temperature range [°C] [max]
- 55 °C
- Temperature range [°C] [min]
- -20 °C
- Temperature range [°F] [max]
- 131 °F
- Temperature range [°F] [min]
- -4 °F
- UL approved refrigerants
- R744
- UL mark
- Yes
Standards & Compliance
- Pressure Rating
- 140 bar
- HS Code
- 8481.80
Compatibility & Fitment
CCMT 10L for CO2 capacity control. Confirm Kv (1.1 m3/h) and MWP (140 bar) against your duty; the matching CCM/ICAD actuator drive and controller are ordered separately.
