Danfoss AB-QM + MSV-S set DN 32 — PICV with partner shut-off valve
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss AB-QM and MSV-S set, DN 32 — a pre-paired terminal-unit assembly combining an AB-QM pressure-independent balancing and control valve on one side of the coil with an MSV-S manual shut-off/drain valve on the other, giving flow control, isolation and drain-down in a single ordered kit. The AB-QM holds design flow independent of network pressure while the MSV-S allows the terminal to be isolated and drained for service. Without test plugs. OEM P/N 003Z1245. EAN 5710104036212. Technical data quoted verbatim from store.danfoss.com (code 003Z1245).
Technical Specifications
- Code number
- 003Z1245
- Type
- AB-QM set
- Product group
- Pressure independent balancing and control valves
- Description
- Set of AB-QM and MSV-S, DN 32
- Valve size
- DN 32
- Test plugs
- Without test plugs
- Contains batteries
- No
- EU RoHS compliance
- Yes with exemptions
- EU RoHS exemption clause
- 6(c)
- China RoHS compliance
- Out of scope
- REACH Candidate List substances
- Lead (CAS no. 7439-92-1)
- Net weight
- 4.386 Kilogram
- Gross weight
- 4.386 Kilogram
- Volume
- 8.315 Liter
- EAN
- 5710104036212
Standards & Compliance
- Classification / Approval
- CE
- HS Code
- 8481.80
Compatibility & Fitment
The set pairs one AB-QM PICV with one MSV-S manual isolation/drain valve for a DN 32 terminal circuit. Fit a compatible M30 x 1.5 actuator on the AB-QM for modulating or on/off control (ordered separately).
