Danfoss MBT 152 temperature sensor insert, Pt 100, 100 mm insertion, cable-terminated

Danfoss MBT 152 replaceable temperature-sensor insert, code 084Z4304 (type designation MBT 152-001-0100-00-0000). The insert carries the Pt 100 platinum measuring element (100 ohm at 0 °C, Class B per EN 60751/IEC 60751) and is the field-replaceable measuring core of the MBT 5252 / box-head MBT sensor connection heads — it is exchanged in service without removing the sensor pocket/thermowell from the process. Insertion length 100 mm; 6 mm protection-tube diameter; Cable, 2-wire connection. Measuring range -50 to +200 °C. Net weight 0.052 kg / gross 0.056 kg; supplied multi pack, 12 pc. EAN 5702423163731. OEM P/N 084Z4304.

Type

Danfoss MBT 152 temperature sensor insert

Type designation

MBT 152-001-0100-00-0000

Code number

084Z4304

Product group

Accessories, sensors (replaceable measuring insert)

Sensor element

Pt 100 platinum resistance (100 ohm at 0 °C)

Element standard

EN 60751 (IEC 60751)

Tolerance class

Class B

Measuring range

-50 to +200 °C

Insertion length

100 mm

Protection tube diameter

6 mm

Connection

Cable, 2-wire

Fits

MBT 5252 / box-head MBT sensor connection heads

Packing format

Multi pack

Quantity per pack

12 pc

Net weight

0.052 kg

Gross weight

0.056 kg

Approvals

CE

EU RoHS

Yes (with exemption 6(c))

Lifecycle status

Current

EAN

5702423163731

Standard

EN 60751

Size / Series

100 mm insertion

Material

AISI stainless-steel protection tube, Pt100 platinum element

Temperature Range

-50 to +200 °C

Classification / Approval

CE

HS Code

9025.90
