Danfoss MCX08M2 programmable controller, 8 relays, 110-230 V, no display, SSR outputs
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss MCX08M2 programmable refrigeration controller with 8 relay outputs, 110-230 V AC supply, without display, for OEM refrigeration and HVAC applications on the MCX platform. Outputs DO5 and DO6 are solid-state relays. CANbus / Modbus communication, real-time clock, buzzer. Supplied as an industrial 24-piece pack. DIN-rail, IP40. EAN 5702428946117.
Technical Specifications
- Type
- MCX08M2 programmable controller
- Function
- Programmable controller, 8 relays
- Supply voltage
- 110-230 V AC
- Frequency
- 50/60 Hz
- Digital inputs (DI)
- 8 pc
- Digital outputs (DO)
- 8 pc (DO5 and DO6 solid-state relays)
- Analog inputs (AI)
- 8 pc
- Analog outputs (AO)
- 4 pc
- Communication
- CANbus; Modbus
- Display
- Without display
- Real-time clock
- Yes
- Buzzer
- Yes
- Enclosure rating
- IP40
- Power consumption
- 10 W
- Battery
- Lithium coin cell CR1620
- Packing
- Industrial pack, 24 pc
- Net weight
- 0.408 kg
- Approvals
- CE, EAC, LLC CDC TYSK, UL
- Danfoss code
- 080G0314
- EAN
- 5702428946117
Standards & Compliance
- IP Rating
- IP40
- Classification / Approval
- CE, EAC, LLC CDC TYSK, UL
- HS Code
- 9032.89
Compatibility & Fitment
Freely programmable OEM controller on the Danfoss MCX platform, 8 relays, no display, 110-230 V AC, with solid-state relays on DO5/DO6 (for high-cycle loads). The RS485-equipped no-display sibling is 080G0316; the LCD single pack is 080G0307. Requires MCX Shape / Design programming tools.
