Meter 1-/3 Phase Mbus

Carlo Gavazzi EM330DINAV53HM1X Manufacturer description: Three-phase Energy analyzer, V L-N 400 to 480 V L-L, 5 (6) A, M-Bus. Energy meter EM330DINAV53HM1X.

Manufacturer part number (MPN)

EM330DINAV53HM1X

EAN / GTIN

8030956069907

Sales unit

pcs

Voltage inputs

1-phase (2-wire), 230 V L-N; 1-phase (2-wire), 240 V L-N; 2-phase (3-wire), 240/480 V; 3-phase (4-wire), 230/400 V; 3-phase ( 4-wire), 240/415 V; 3-phase (4-wire), 277/480 V; 3-phase (3-wire), 400 V L-L; 3-phase (3-wire), 415 V L-L; 3-phase (3-wire), 480 V L-L

Frequency

50Hz; 60Hz

Energy metering

Consumption and generation

Communication port and protocol

M-Bus

Power supply

Auxiliary power supply 220-240 Vac

Approvals, marks, declarations

CE (Europe); UKCA (UK)

E-number (NO)

8200711

E-number (SE)

0933010

Mounting method

DRA (DIN-rail adaptor)

Model

Measurement transformer

Suitable for

Purchase/supply

Type of indication

Digital

Max. current (Imax)

6 A

Width in number of modular spacings

3

Number of positions total (counter)

8

Type of meter

Electronic

Degree of protection (IP)

IP51

Type of interface

M-bus (wired)

Energy type

Effective power and reactive power

Tariff type

Two-tariff

Tariff control

External

Escapement mechanism

Yes

Calibrated

Yes

Approval

Domestic

Pulse output

Optical

Accuracy class

B

Pole type

Three conductor/four conductor

Measurement type load profile

No

EEC40 signature

No

With lock code

Yes

Nominal voltage (Un) N-L

230–277 V

Nominal voltage (Un) L-L

400–480 V

Nominal current (In)

5 A

Country of origin

China

HS Code

9030.90

• EAN 8030956069907
• SAP 1200454065
• Code 82514728
