Bürkert Pressure Transmitter for General Applications, 0...25 Bar

This pressure transmitter is designed to cover the majority of industrial applications in the field of pressure measurement technology. High accuracy, compact design, robust construction and flexibility make the transmitter suitable for different measurement functions. For technical reasons, the piezoresistive sensor element is used for measuring ranges up to 16 bar and thin film sensor element for the measuring range of 25 bar. All wetted parts are made of stainless steel and completely welded. Internal seal elements, which could restrict the choice of measuring media, are excluded.

Housing

Stainless steel 1.4301 (304)

Standard version

Stainless steel 1.4471 (316Ti)

Standard flush diaphragm version

Stainless steel 1.4471 (316Ti), FKM seal

Hygienic flush diaphragm version

Stainless steel 1.4404 (316L), EPDM seal

Internal transmitting liquid

Synthetic Oil (for standard version with pressure range < 16 bar (232 PSI) and for all flush

Measurement technology

Piezo (≤ 16 bar) / Thin film (25 bar)

Compensated T° range

0…+ 80 °C (+ 32…+ 176 °F)

Welding socket for pressure transmitter

Standard flush diaphragm version: G ½" B or G 1" B

Temperature coefficient (Tc)

In compensated T° range

Flush diaphragm version

≤ - 0.2…+ 0.3 % of full scale/10K

Standard and flush diaphragm version

≤ ± 0.2 % of full scale/10K

Response time

≤ 1 ms

Measurement deviation

≤ 0.5 % of full scale (2-point calibration)1.)

Hysteresis

≤ 0.1 % of full scale

Repeatability

≤ 0.05 % of full scale

HS Code

9026.20
