Bürkert Direct-acting 2-Way Proportional Valve Type 6020

The direct-acting proportional valve Type 6020 can be used as a control valve for closed-loop process control, typically for automatic setpoint control of flow or pressure values. Due to an elastomeric seat seal, the valve closes tight in the range of the nominal pressure related to the orifice size (integrated shut-off function). This valve is particularly suitable for use with gases such as hydrogen, oxygen or fuel gases. Compared to conventional proportional valves, the valve can be operated at higher supply pressures. For optimized use in fuel cell systems, cartridge and subbase (manifold) valve bodies as well as solenoids with automotive connector of protection class IP6K9K are available.

Seal

EPDM, FKM

Body

Stainless steel 1.4404/316L

Tightness

1x 10 - 4 mbar l/s

Orifice

DN 0.8…DN 8

Thermal insulation class of

Epoxy coil class H

Response sensitivity

< 1 % FS

Hysteresis

< 15 %

Repeat accuracy

< 1 % FS

Setting range

1:100

Burst pressure

Coil size 32 mm and 40 mm (AC10) Coil size 42 mm (AC19)

Differential pressure

0…30 bar

Duty cycle

100 % continuous operation

Operating voltage

12 V DC, 24 V DC

Power consumption

Coil size 32 mm and 40 mm (AC10) Coil size 42 mm (AC19)

Maximum coil current

Coil size 32 mm and 40 mm (AC10) Coil size 42 mm (AC19)

HS Code

8481.80
