Abiko 6-6 Copper Tube Cable Lug 6 mm² M6, 90° Angled Palm

Abiko 6-6 90GR — compression (crimp) copper tube cable lug for terminating a 6 mm² conductor onto an M6 stud. The barrel is formed from 99.95% electrolytic copper, tin-plated (Cu/Sn), with a ring tongue and a cable inspection hole for correct conductor insertion. The palm is set at 90° to the barrel, for terminations that turn away from the stud. Accepts stranded (IEC 60228 Class 2) and flexible (Class 5) copper conductors; crimped with matching Abiko/Elpress dies to a gas-tight, low-resistance connection whose crimp performance is verified to IEC 61238-1. Applied in low-voltage power distribution, switchboards, motor terminations and marine and offshore installations.

Type

Compression (crimp) copper tube cable lug (ring tongue), 90° angled palm

Conductor cross-section

6 mm²

Stud / bolt hole

M6

Conductor class

Stranded (IEC 60228 Cl.2) & flexible (Cl.5) copper

Material

Electrolytic copper 99.95%, tin-plated (Cu/Sn)

Feature

Cable inspection hole

Crimp system

Crimp connection, performance verified to IEC 61238-1

Manufacturer part number (MPN)

6-6 90GR

EAN / GTIN

7070920007789

Sales unit

pcs

Package quantity

100 pcs

HS code

8536.90

HS Code

8536.90

• EAN 7070920007789
• SAP 1200071996
• Code 81922753
