ABB Contactor AF16Z-22-00-20, 2 NO + 2 NC, 12–20 V DC Coil, <500 mA, PLC-Compatible
Pricing
Request a quote
We reply within 24 hours
Product Description
ABB AF16Z-22-00-20 contactor with 2 NO + 2 NC main contacts and a 12–20 V DC electronic coil drawing less than 500 mA, suitable for direct control from PLC outputs.
Technical Specifications
- Manufacturer part number (MPN)
- AF16Z-22-00-20 12-20VDC
- EAN / GTIN
- 3471523116702
- HS code
- 8536.90
- Sales unit
- pcs
- Width
- 45 mm
- Height
- 86 mm
- Depth
- 77 mm
- Suitable for distribution board
- No
- Rated operation power at AC-3, 400 V
- 7.5 kW
- Number of normally open contacts as main contact
- 2
- Number of normally closed contacts as main contact
- 2
- Rated operation current Ie at AC-3, 400 V
- 18 A
- Rated operation current Ie at AC-1, 400 V
- 30 A
- Rated control supply voltage AC 50 Hz
- 12–20 V
- Rated control supply voltage AC 60 Hz
- 12–20 V
- Rated control supply voltage DC
- 12–20 V
- Type of electrical connection of main circuit
- Screw connection
- Operating voltage AC 50 Hz
- 690 V
- Operating voltage AC 60 Hz
- 690 V
- Voltage type for actuating
- DC
- Country of origin
- France
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 3471523116702
- SAP 1000225357
- Code 8945874
Product Documentation
More from ABB Automasjon
ABB Automasjon
DREIE.Hand. RHD T4-T5 F/P
ABB Automasjon
Blanking Module 1B2A
2CPX037632R9999
ABB Automasjon
ABB GHL5301904R0001 SZ-BP1 Terminals and Installation Material
ABB Automasjon
Mateklemme ZLS251 FOR L1
2CCV672501R0001
ABB Automasjon
Circuit Breaker S803S-C20
2CCS863001R0204
ABB Automasjon
ABB Automasjon MS 1XX-AA 1-110 Shunt Trip 110 V for MS116/MS132
ABB Automasjon
Residual Current Circuit Breaker F204 R 25/0,03
2CSF204401R1250
ABB Automasjon
Circuit Breaker S804S-D25
2CCS864001R0251
Technical guides
Catalogue entry last verified: 2026-10-02. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy AF16Z-22-00-20 12-20VDC?
- AF16Z-22-00-20 12-20VDC can be ordered from cballast.com as a ABB Automasjon catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this ABB Automasjon product?
- The manufacturer part number is AF16Z-22-00-20 12-20VDC.
- What is the HS code for AF16Z-22-00-20 12-20VDC?
- The customs tariff (HS) code for AF16Z-22-00-20 12-20VDC is 8536.90.
- Who manufactures AF16Z-22-00-20 12-20VDC?
- AF16Z-22-00-20 12-20VDC is a ABB Automasjon product in the Electrical Components range.
- Is a datasheet available for AF16Z-22-00-20 12-20VDC?
- Yes — the AF16Z-22-00-20 12-20VDC datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for AF16Z-22-00-20 12-20VDC?
- The minimum order quantity is 1.
- Is AF16Z-22-00-20 12-20VDC available?
- Yes — AF16Z-22-00-20 12-20VDC is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
