Circuit Breaker S803S-C20
Pricing
Request a quote
We reply within 24 hours
Product Description
ABB Automasjon 2CCS863001R0204 S800S, 50kA Icu, 3Pol, C-characteristic, 20A.
Technical Specifications
- Manufacturer part number (MPN)
- 2CCS863001R0204
- EAN / GTIN
- 7612271200756
- HS code
- 8536.90
- Sales unit
- pcs
- Rated current
- 20 A
- Tripping characteristic
- C
- Power loss
- 10.5 W
- Built-in depth
- 82.5 mm
- Release characteristic
- C
- Number of poles (total)
- 3
- Number of protected poles
- 3
- Rated voltage
- 400 V
- Rated insulation voltage Ui
- 690 V
- Rated impulse withstand voltage Uimp
- 8 kV
- Frequency
- 50–60 Hz
- Current limiting class
- 3
- Concurrently switching neutral conductor
- No
- Overvoltage category
- 4
- Pollution degree
- 3
- Additional equipment possible
- Yes
- Width in number of modular spacings
- 4.5
- Degree of protection (IP)
- IP20
- Ambient temperature during operating
- -40–70 °C
- Connectable conductor cross section multi-wired
- 0–50 mm²
- Connectable conductor cross section solid-core
- 0–70 mm²
- Explosion-proof
- No
- Flush-mounted installation
- No
- Country of origin
- Switzerland
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 7612271200756
- SAP 1000006217
- Code 833673
Product Documentation
More from ABB Automasjon
ABB Automasjon
ABB Automasjon MS 1XX-AA 1-110 Shunt Trip 110 V for MS116/MS132
ABB Automasjon
Residual Current Circuit Breaker F204 R 25/0,03
2CSF204401R1250
ABB Automasjon
Circuit Breaker S804S-D25
2CCS864001R0251
ABB Automasjon
EFF.BR.3P T5N 630-Lsi In=630
T5N 630 PR222DS/P-LSI In=630 3p F F
ABB Automasjon
AF26Z-40-00, 24-60VAC/20-60VDC (AF26Z-40-00-21 24-60V50/60HZ 20-60VDC)
ABB Automasjon
ABB TF42-16 Thermal Overload Relay, 13.0-16.0 A
ABB Automasjon
Motor Protection Circuit Breaker MS116- 1,0
MS116-1.0
ABB Automasjon
ZLS 101 (2CCF002763R0001)
Catalogue entry last verified: 2026-09-29. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy 2CCS863001R0204?
- 2CCS863001R0204 can be ordered from cballast.com as a ABB Automasjon catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this ABB Automasjon product?
- The manufacturer part number is 2CCS863001R0204.
- What is the HS code for 2CCS863001R0204?
- The customs tariff (HS) code for 2CCS863001R0204 is 8536.90.
- Who manufactures 2CCS863001R0204?
- 2CCS863001R0204 is a ABB Automasjon product in the Electrical Components range.
- Is a datasheet available for 2CCS863001R0204?
- Yes — the 2CCS863001R0204 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for 2CCS863001R0204?
- The minimum order quantity is 1.
- Is 2CCS863001R0204 available?
- Yes — 2CCS863001R0204 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
