ABB NHP 100009R0001 DK 240/50 / 400 A / 50mm Feeding module
Pricing
Request a quote
We reply within 24 hours
Overview
ABB Automasjon ABB NHP 100009R0001 DK 240/50 / 400 A / 50mm Feeding module is listed under Electrical Components / Busbar Systems. Sales unit: pcs; Package quantity: 119 pcs; Environmental Information: 1SEP501005P0001; Degree of Protection: acc. to IEC 60529 IP20; Product Net Width: 50 mm; Product Net Height: 480 mm.
Technical Specifications
- Manufacturer part number (MPN)
- NHP 100009R0001
- EAN / GTIN
- 7025840008835
- Sales unit
- pcs
- Package quantity
- 119 pcs
- Environmental Information
- 1SEP501005P0001
- Environmental Product Declaration - EPD
- 2CGC0156
- Degree of Protection
- acc. to IEC 60529 IP20
- Product Net Width
- 50 mm
- Product Net Height
- 480 mm
- Product Net Depth / Length
- 160 mm
- Cable Cross-Section
- 95 ... 240 mm²
- Connecting Capacity
- 95 ... 240 mm²
- Conventional Free-air Thermal Current (I th )
- 400 A
- Conventional Thermal Current (I the )
- 400 A
- Mounting Type
- 100mm FS/FST Busbar System
- Number of Poles
- 3P
- Rated Operational Voltage
- Main Circuit 500 V
- Terminal Type
- Screw Terminals
- Declaration of Conformity - CE
- 1SEP500020P0001
- Object Classification Code
- Q
- ETIM 9
- EC000001 - Busbar terminal
- UNSPSC
- 39120000
- eClass
- V11.1 : 27141146
- WEEE Category
- 4. Large Equipment (Any External Dimension More Than 50 cm)
- E-Number (Norway)
- 1144085
- EAN
- 7331980002085
Standards & Compliance
- HS Code
- 8538.10
Cross References
- EAN 7025840008835
- SAP 1000016230
- Code 8487232
