ABB 2CDE300010R1601 E233-12/48 is a working hour meter, working with 12 or 48V voltage and 50Hz frequency
Pricing
Request a quote
We reply within 24 hours
Overview
ABB 2CDE300010R1601 E233-12/48 is a working hour meter, working with 12 or 48V voltage and 50Hz frequency is listed under Electrical Components / Circuit Breaker Accessories. Sales unit: pcs; Package quantity: 10 pcs; Accuracy: Reading Accuracy Class 0,01 h; Rated Voltage (U r ): 12 ... 48 V DC; Rated Frequency (f): 50 / 60 Hz; Power Loss: 0.02 W.
Technical Specifications
- Manufacturer part number (MPN)
- 2CDE300010R1601
- EAN / GTIN
- 4012233630202
- Sales unit
- pcs
- Package quantity
- 10 pcs
- Accuracy
- Reading Accuracy Class 0,01 h
- Rated Voltage (U r )
- 12 ... 48 V DC
- Rated Frequency (f)
- 50 / 60 Hz
- Power Loss
- 0.02 W
- Width in Number of Modular Spacings
- 1
- Product Net Width
- 17.5 mm
- Product Net Height
- 85 mm
- Product Net Depth / Length
- 58 mm
- Declaration of Conformity - CE
- 2CDK443001D0403
- EU Data Act Compliance Declaration
- Not applicable
- Instructions and Manuals
- 2CSC400002D0208
- ETIM 9
- EC001641 - Hour meter
- UNSPSC
- 41111949
- eClass
- V11.0 : 27142313
- IDEA Granular Category Code (IGCC)
- 6132 >> Counters
- Object Classification Code
- P
- Mounting method
- DIN rail
- Model
- Analogue
- Count area
- 99999 h
- Reset function
- None
- Operation indication
- Yes
- Number of digits
- 6
- Input voltage
- 48 V
- Voltage type
- DC
- Type of drive
- Quartz
- Accuracy per day
- 144 s
- Width
- 17.5 mm
- Height
- 85 mm
- Built-in depth
- 64 mm
- Degree of protection (IP)
- IP20
- Country of origin
- Germany
Standards & Compliance
- HS Code
- 9029.10
Cross References
- EAN 4012233630202
- SAP 1200640228
- Code 83057427
Product Documentation
