ABB SACE Tmax XT4X 160 Moulded-Case Circuit Breaker — MA 32 Im=160, In=32 A, 3-Pole
Pricing
Request a quote
We reply within 24 hours
Product Description
ABB SACE Tmax XT4X 160 A frame moulded-case circuit breaker (MCCB). Rated uninterrupted current In = 32 A, 3-pole, F/F (front, fixed) terminals. Magnetic-only trip unit MA 32 Im=160 (magnetic instantaneous short-circuit release, for motor protection). Breaking-capacity class X; rated ultimate short-circuit breaking capacity Icu = 200 kA at 415 V AC; rated operational voltage Ue 690 V AC. Conforms to IEC/EN 60947-2. ABB order code 1SDA107708R1, EAN 8056221028509, ABB/SAP material 1200638060, catalogue code 83053790.
Technical Specifications
- Manufacturer
- ABB
- Product family
- SACE Tmax XT4 (moulded-case circuit breaker, IEC 60947-2)
- Configuration
- XT4X 160 MA 32 Im=160...320 3p FF
- ABB order code (MPN)
- 1SDA107708R1
- EAN / GTIN
- 8056221028509
- ABB / SAP material no.
- 1200638060
- Frame
- XT4 (160 A frame)
- Breaking-capacity class
- X
- Rated ultimate breaking capacity Icu (415 V AC)
- 200 kA
- Trip unit
- MA 32 Im=160
- Rated uninterrupted current In
- 32 A
- Poles
- 3
- Terminals
- F/F (front, fixed)
- Rated operational voltage Ue
- 690 V AC
- Standard
- IEC/EN 60947-2
- HS code
- 8536.20
- Sales unit
- pcs
Standards & Compliance
- Standard
- IEC/EN 60947-2
- HS Code
- 8536.20
Cross References
- EAN 8056221028509
- SAP 1200638060
- Code 83053790
Product Documentation
More from ABB
ABB
Residual Current Circuit Breaker F404 B 63A/300MA
2CCG000057R0001
ABB
Main Circuit BREAKER S754DR-E50 SEL
2CDH784001R0502
ABB
Residual Current Circuit Breaker WITH Overcurrent DS202CRM CK32A 30MA
2CSR772140R1323
ABB
PIPE BEND 20mm JMKL20.4 Halogen-FREE
JMKL20.4HF
ABB
Tenton 3/6V White MATT SBC/U6.0.1-884
ABB
ABB SACE Tmax XT4X 250 Moulded-Case Switch-Disconnector — 4-Pole
1SDA100268R1
ABB
ABB 1SDA100616R1 Thermomagnetic Release Three-POLE IN AC-DC MA R 500 I3=3500...6500 XT5
ABB
Residual Current Circuit Breaker F404 B 40A/300MA
