ABB SACE Tmax XT4S 250 Moulded-Case Circuit Breaker — Ekip LS/In, In=250 A, 4-Pole
Pricing
Request a quote
We reply within 24 hours
Product Description
ABB SACE Tmax XT4S 250 A frame moulded-case circuit breaker (MCCB). Rated uninterrupted current In = 250 A, 4-pole, F/F (front, fixed) terminals. Electronic trip unit Ekip LS/In (L overload, S short-time-delay, I instantaneous protection). Breaking-capacity class S; rated ultimate short-circuit breaking capacity Icu = 50 kA at 415 V AC; rated operational voltage Ue 690 V AC. Conforms to IEC/EN 60947-2. ABB order code 1SDA068495R1, EAN 8015644024017, ABB/SAP material 1000643056, catalogue code 8327976.
Technical Specifications
- Manufacturer
- ABB
- Product family
- SACE Tmax XT4 (moulded-case circuit breaker, IEC 60947-2)
- Configuration
- XT4S 250 Ekip LS/In In=250A 4p FF
- ABB order code (MPN)
- 1SDA068495R1
- EAN / GTIN
- 8015644024017
- ABB / SAP material no.
- 1000643056
- Frame
- XT4 (250 A frame)
- Breaking-capacity class
- S
- Rated ultimate breaking capacity Icu (415 V AC)
- 50 kA
- Trip unit
- Ekip LS/In
- Rated uninterrupted current In
- 250 A
- Poles
- 4
- Terminals
- F/F (front, fixed)
- Rated operational voltage Ue
- 690 V AC
- Standard
- IEC/EN 60947-2
- HS code
- 8536.20
- Sales unit
- pcs
Standards & Compliance
- Standard
- IEC/EN 60947-2
- HS Code
- 8536.20
Cross References
- EAN 8015644024017
- SAP 1000643056
- Code 8327976
Product Documentation
More from ABB
ABB
ABB 1SDA054878R1 Shunt Opening Release Wired FOR Permanent Service 24V AC-DC T4-T5-T6
ABB
Contactor AF116-30-11-12
ABB
HTC-ES XT6 4P (1SDA105034R1)
ABB
OVR T1-T2 1N 12.5-440S P TS QS
2CTB815710R3000
ABB
Residual Current Circuit Breaker WITH Overcurrent DS201 M C40 A300MA
2CSR275180R3404
ABB
UNIV.SWITCHGR.US/U12.2 (pille) (us/U 12.2)
US/U 12.2
ABB
TMA 630-6300 XT6 4P (1SDA107611R1)
ABB
Endecoupling AJF5.20MM Flexible
2TKA00004194
Catalogue entry last verified: 2026-09-29. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy 1SDA068495R1?
- 1SDA068495R1 can be ordered from cballast.com as a ABB catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this ABB product?
- The manufacturer part number is 1SDA068495R1.
- What is the HS code for 1SDA068495R1?
- The customs tariff (HS) code for 1SDA068495R1 is 8536.20.
- Who manufactures 1SDA068495R1?
- 1SDA068495R1 is a ABB product in the Electrical Components range.
- Is a datasheet available for 1SDA068495R1?
- Yes — the 1SDA068495R1 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for 1SDA068495R1?
- The minimum order quantity is 1.
- Is 1SDA068495R1 available?
- Yes — 1SDA068495R1 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
