ABB SACE Tmax XT2N 160 Moulded-Case Circuit Breaker — TMA 125-1250, In=125 A, 4-Pole
Pricing
Request a quote
We reply within 24 hours
Product Description
ABB SACE Tmax XT2N 160 A frame moulded-case circuit breaker (MCCB). Rated uninterrupted current In = 125 A, 4-pole, F/F (front, fixed) terminals. Thermomagnetic trip unit TMA 125-1250 (adjustable thermal overload and magnetic short-circuit release). Breaking-capacity class N; rated ultimate short-circuit breaking capacity Icu = 36 kA at 415 V AC; rated operational voltage Ue 690 V AC; neutral pole rated 100% of In. Conforms to IEC/EN 60947-2. EAN 8015644009489, ABB/SAP material 1000669187, catalogue code 8266303.
Technical Specifications
- Manufacturer
- ABB
- Product family
- SACE Tmax XT2 (moulded-case circuit breaker, IEC 60947-2)
- Configuration
- XT2N 160 TMA 125-1250 4p FF InN=100%
- EAN / GTIN
- 8015644009489
- ABB / SAP material no.
- 1000669187
- Frame
- XT2 (160 A frame)
- Breaking-capacity class
- N
- Rated ultimate breaking capacity Icu (415 V AC)
- 36 kA
- Trip unit
- TMA 125-1250
- Rated uninterrupted current In
- 125 A
- Poles
- 4
- Neutral pole rating
- 100% of In
- Terminals
- F/F (front, fixed)
- Rated operational voltage Ue
- 690 V AC
- Standard
- IEC/EN 60947-2
- HS code
- 8536.20
- Sales unit
- pcs
Standards & Compliance
- Standard
- IEC/EN 60947-2
- HS Code
- 8536.20
Cross References
- EAN 8015644009489
- SAP 1000669187
- Code 8266303
