WIKA 262.50 Monel Bourdon gauge 0-25 bar NS100 G1/2 B
Pricing
Request a quote
We reply within 24 hours
Product Description
WIKA model 262.50 Bourdon-tube pressure gauge, NS 100, 0 to 25 bar, lower mount G1/2 B. Stainless steel case with Monel 400 wetted parts for aggressive and sour-gas media. Accuracy class 1.0 per EN 837-1, safety level S1 (blow-out device). Dry case version.
Technical Specifications
- Model
- 262.50
- Nominal size
- NS 100 (100 mm dial)
- Scale range
- 0 to 25 bar
- Accuracy
- class 1.0 per EN 837-1
- Case
- stainless steel, dry
- Wetted parts
- Monel 400 (2.4360 / N04400)
- Process connection
- G1/2 B male, lower mount (radial)
- Window
- laminated safety glass
- Safety
- blow-out device (EN 837-1 safety level S1)
- Ingress protection
- IP54 per IEC/EN 60529
- Media
- aggressive / sour gas (NACE on request)
- Standards
- EN 837-1, ASME B40.100
Standards & Compliance
- Standard
- EN 837-1
- Size / Series
- 100 mm
- Material
- Stainless steel case; Monel 400 (2.4360 / N04400) wetted parts (Bourdon tube + socket)
- Thread Standard
- G1/2 B male (EN 837-1)
- Pressure Rating
- 0 to 25 bar
- Temperature Range
- -20 to +60 °C ambient
- IP Rating
- IP54
- Classification / Approval
- EN 837-1 / ASME B40.100
- HS Code
- 9026.20
Compatibility & Fitment
WIKA 262.50 Monel-wetted Bourdon gauges suit aggressive acids/bases where 316L is insufficient. Interchange with equivalent EN 837-1 Monel-wetted gauges at the same nominal size, process connection and scale range. Confirm wetted material (Monel 400), connection thread and mount before ordering.
