Wibe Group 783508 Adjustable Cantilever Arm W1860-500 White Painted Steel
Pricing
Request a quote
We reply within 24 hours
Product Description
Wibe Group 783508 is an adjustable cantilever arm W1860-500 in pre-galvanized steel finished in NCS S 0500-N white, for cable-ladder installations 500 mm wide. Corrosion class C2 with a maximum safe working load of 764 N per IEC 61537.
Technical Specifications
- Manufacturer part number (MPN)
- 783508
- EAN / GTIN
- 7321677835089
- Sales unit
- pcs
- Package quantity
- 2 pcs
- Colour
- White NCS S 0500 N gl30
- Material
- Steel
- Material type or surface treatment
- Painted
- Corrosion class
- C2
- Length
- 539 mm
- Width
- 60 mm
- Height
- 160 mm
- Suitable for cable management system width
- 500 - 500 mm
- Model
- Wall- and profile console
- Angle
- 90 - 90 °
- Suitable for circuit integrity
- No
- Material quality
- Other
- Surface protection
- Continuously galvanized and coated
- Max. safe working load according to IEC 61537
- 764 N
- Pack 1 type
- Each
- Quantity pack 1
- 1
- Weight pack 1
- 1.61 kg
- Length pack 1
- 0 mm
- Width pack 1
- 0 mm
- Height pack 1
- 0 mm
- Net weight
- 1.61 kg
- Country of origin
- SE
- ETIM class
- EC000022
Standards & Compliance
- HS Code
- 7308.90
Cross References
- EAN 7321677835089
- SAP 1000779941
- Code 81391092
