Wibe Group CSU796016 W4-100 Vertical Riser Bend Steel Zinc+
Pricing
Request a quote
We reply within 24 hours
Product Description
Wibe Group CSU796016 is a W4-100 vertical adjustable riser bend for cable tray systems, in steel with a Zinc+ surface treatment to corrosion class C4. The segmental bend allows an adjustable angle for rising or descending runs, sized for a 100 mm wide tray at 15 mm side wall height. It measures 250 x 102 x 16 mm, is hot-dip galvanized in the connector interface and has a mounting-perforated bottom for tray attachment.
Technical Specifications
- Manufacturer part number (MPN)
- CSU796016
- EAN / GTIN
- 7321677960163
- Sales unit
- pcs
- Length
- 250 mm
- Width
- 102 mm
- Height
- 16 mm
- Material
- Steel
- Material type or surface treatment
- Zinc+
- Corrosion class
- C4
- Change of direction
- Rising/descending
- Angle
- Adjustable
- Construction type
- Vertical adjustable bend element
- Bend model
- Segmental bend
- With cover
- No
- Cable tray height
- 15 mm
- Cable tray width
- 100 mm
- Material thickness
- 1 mm
- Side wall perforation
- No
- Mounting perforation in bottom
- Yes
- NATO
- Yes
- Model
- Without connector
- Suitable for circuit integrity
- No
- Stainless steel, pickled
- No
- Surface protection
- Hot-dip galvanized
- Pack 1 type
- Each
- Quantity pack 1
- 1
- Weight pack 1
- 0.28 kg
- Length pack 1
- 250 mm
- Width pack 1
- 102 mm
- Height pack 1
- 16 mm
- Net weight
- 0.28 kg
- Country of origin
- SE
- ETIM class
- EC002400
- GWP Total A1-A3
- 0.7952 kgCO2e
Standards & Compliance
- HS Code
- 7308.90
Cross References
- EAN 7321677960163
- SAP 1200851979
- Code 84073124
Product Documentation
