End and separator plate, for 2-Conductor longitudinal switching disconnect terminal block
Pricing
Request a quote
We reply within 24 hours
Product Description
WAGO 282-360 Manufacturer description: End and separator plate; for 2-conductor longitudinal switching disconnect terminal block; 1.5 mm thick; gray. End- and separatorplate; for 2-conductor longitudinal vekslings-disconnect terminal; 1,5 mm thick; grey.
Technical Specifications
- Manufacturer part number (MPN)
- 282-360
- EAN / GTIN
- 4017332813044
- Sales unit
- pcs
- Package quantity
- 10 pcs
- Width
- 1.5 mm / 0.059 inches
- Height
- 98 mm / 3.858 inches
- Depth
- 46.5 mm / 1.831 inches
- Color
- gray
- Material group
- I
- Insulation material (main housing)
- Polyamide (PA66)
- Flammability class per UL94
- V0
- Fire load
- 0.086 MJ
- Weight
- 2.9 g
- Processing temperature
- -35 … +85 °C
- Continuous operating temperature
- -60 … +105 °C
- Product Group
- 1 (Rail Mounted Terminal Blocks)
- PU (SPU)
- 50 (10) pcs
- Packaging type
- box
- Country of origin
- CN
- Customs tariff number
- 85389099990
- UNSPSC
- 39,121,402
- eCl@ss 10.0
- 27-14-11-33
- eCl@ss 9.0
- 27-14-11-33
- ETIM 9.0
- EC000886
- ETIM 10.0
- EC000886
- ECCN
- NO US CLASSIFICATION
- RoHS Compliance Status
- Compliant,No Exemption
- MPN
- 282-360
- Colour
- Grey
- Thickness
- 1.5 mm
- Snap in
- Yes
- End plate model
- Yes
- Partition model
- Yes
Standards & Compliance
- HS Code
- 8538.90
Cross References
- EAN 4017332813044
- SAP 1200635375
- Code 83049018
