VEGA pressure transmitter with metallic measuring cell

VEGA VEGABAR 19 process pressure transmitter with metallic (piezoresistive) measuring cell, for gases, vapours and liquids including aggressive media. Entry-level device for general industrial use. Measuring range -1. +100 bar with smallest range 0.4 bar, accuracy deviation < 0.5 %. Process temperature -40. +100 °C. Two-wire 4. 20 mA output, loop powered. Thread process fitting from G1/2 / 1/2 NPT, 316L wetted parts. No on-site display. Supplied as a VEGA configured item; confirm the order code for your exact range, fitting and electronics.

Type

VEGA VEGABAR 19

Measuring cell

metallic process diaphragm, piezoresirigide / strain gauge

Media

gases, vapours and liquids, also aggressive products

Measuring range

-1 ... +100 bar / -100 ... +10000 kPa (-14.5 ... +1450 psig)

Smallest adjustable range

0.4 bar / 40 kPa (5.802 psig)

Accuracy (deviation)

< 0.5 %

Process temperature

-40 ... +100 °C (-40 ... +212 °F)

Isolating system

synthetic oil

Process fitting

thread from G1/2, 1/2 NPT

Process fitting / diaphragm material

316L

Signal output

4 ... 20 mA (two-wire, loop powered)

Communication / indication / adjustment

none

Electrical connection

plug connector to ISO 4400 or M12 x 1

Degree of protection

IP65 (ISO 4400 plug) / IP66 / IP67

Approvals

CE (optional Ex / regional approvals available or applied for)

Material

Metallic process diaphragm (316L); piezoresistive sensor element

Pressure Rating

-1 ... +100 bar

Temperature Range

-40 °C to +100 °C

IP Rating

IP65/IP66/IP67

Classification / Approval

CE

HS Code

9026.20
