VEGA non-contact 80 GHz radar level sensor VEGAPULS C 11

VEGA VEGAPULS C 11 non-contact radar level sensor for continuous level measurement of liquids and bulk solids in standard applications. 80 GHz radar with an 8° beam angle, measuring range to 10 m and accuracy ± 5 mm. Plastic housing with PVDF process fitting, FKM seal and axial PVC cable outlet (10 m). Two-wire 4. 20 mA loop-powered output. Degree of protection IP66/IP68 (3 bar). Used in water treatment, pumping stations, rain-overflow basins and open-channel flow. Supplied as a VEGA configured item; confirm the order code for the required range, process fitting, cable length and electronics.

Type

VEGA VEGAPULS C 11

Measuring principle

non-contact radar, 80 GHz (W-band)

Media

liquids and bulk solids

Measuring range

up to 10 m (33 ft)

Accuracy (deviation)

± 5 mm (± 0.2 in)

Beam angle

8°

Process temperature

-40 ... +60 °C (-40 ... +140 °F)

Process pressure

-1 ... +3 bar (-100 ... +300 kPa)

Ambient temperature

-40 ... +60 °C

Process fitting

thread G1½ / G1, 1½ NPT / 1 NPT, R1½ / R1

Wetted parts material

PVDF

Seal material

FKM

Housing material

plastic

Signal output

4 ... 20 mA (two-wire, loop powered)

Electrical connection

axial cable outlet, PVC cable 10 m

Degree of protection

IP66 / IP68 (3 bar), Type 6P

Approvals

CE (optional Ex / regional / ship approvals available per configuration)

Material

PVDF wetted parts; FKM seal; plastic housing

Pressure Rating

-1 ... +3 bar

Temperature Range

-40 °C to +60 °C

IP Rating

IP66/IP68 (3 bar)

Classification / Approval

CE

HS Code

9026.10
