Telemecanique OsiSense XS8E1A1MBL01U20 Inductive Proximity Sensor — 26 × 26 mm block, Sn 15 mm, 2-Wire AC/DC, NC, screw terminals
Pricing
Request a quote
We reply within 24 hours
Product Description
Telemecanique XS8E1A1MBL01U20 is an OsiSense XS inductive proximity sensor in a 26 × 26 mm PBT thermoplastic rectangular block housing, with a nominal sensing distance (Sn) of 15 mm. It provides a 2-wire AC/DC output, switching NC (normally closed), via screw terminals. Rated supply 24…240 V AC/DC, operating range -25 °C to +70 °C, with output-state LED indication. Conforms to IEC 60947-5-2.
Technical Specifications
- Manufacturer part number (MPN)
- XS8E1A1MBL01U20
- EAN / GTIN
- 3666916009642
- Product type
- OsiSense XS inductive proximity sensor
- Housing
- 26 × 26 mm rectangular block housing (PBT thermoplastic)
- Nominal sensing distance Sn
- 15 mm
- Output
- 2-wire AC/DC
- Switching function
- NC (normally closed)
- Connection
- screw terminals
- Rated supply voltage
- 24…240 V AC/DC
- Operating temperature
- -25 °C to +70 °C
- Conforms to
- IEC 60947-5-2
- HS code
- 8536.50
- Sales unit
- pcs
- Package quantity
- 20 pcs
Standards & Compliance
- Standard
- IEC 60947-5-2
- Material
- PBT thermoplastic
- Temperature Range
- -25 °C to +70 °C
- HS Code
- 8536.50
Cross References
- EAN 3666916009642
