Telemecanique XCSDMP5902 Coded Magnetic Safety Switch, 1 NC + 1 NO, 2 m cable
Pricing
Request a quote
We reply within 24 hours
Product Description
Telemecanique XCSDMP5902 coded magnetic safety interlock switch for guard-door monitoring, 1 NC + 1 NO contacts, 2 m cable.
Technical Specifications
- Manufacturer part number (MPN)
- XCSDMP5902
- EAN / GTIN
- 3666916059784
- HS code
- 8544.42
- Sales unit
- pcs
- Package quantity
- 20 pcs
- Contact configuration
- NC + NO
- Number of protected contact energized outputs
- 2
- Type of actuation
- Magnet
- Type of electric connection
- Cable radial
- Type of switching output
- Relay contact
- Width sensor
- 25 mm
- Height of sensor
- 88 mm
- Length of sensor
- 13 mm
- Explosion safety category for gas
- None
- Explosion safety category for dust
- None
- Construction type housing
- Cuboid
- Housing material
- Plastic
- Coating housing
- Uncoated
- Protected switch distance OFF
- 20 mm
- Protected switch distance ON
- 8 mm
- SIL according to IEC 61508
- 3
- Performance level according to EN ISO 13849-1
- Level e
- Max. output current at protected output
- 100 mA
- Min. output current
- 100 mA
- Voltage type
- AC/DC
- Cross-/short circuit identification possible
- No
- Switching distance
- 20 mm
- With monitoring function downstream switching devices
- No
- Suitable for safety functions
- Yes
- With status indication
- No
- Degree of protection (IP)
- IP66
- Country of origin
- France
Standards & Compliance
- HS Code
- 8544.42
Cross References
- EAN 3666916059784
- SAP 1000342316
- Code 81106741
Product Documentation
More from Telemecanique
Telemecanique
Telemecanique XY2CZ503 Emergency Stop Rope Pull Switch
Telemecanique
Telemecanique OsiSense XS4P12PA340L1 Inductive Proximity Sensor — M12 barrel, Sn 4 mm, PNP, NO, pre-wired cable
Telemecanique
Telemecanique ZBY0101 Blank Legend Plate 8x27 mm, Black/Red
Telemecanique
Telemecanique XMLP250MC21FQ Pressure Transmitter, 0.5–4.5 V ratiometric, G 1/4
Telemecanique
Telemecanique XCSP safety limit switch, plastic body, rotary lever with steel roller, 2 NC + 1 NO with positive opening, M20 x 1.5 cable entry, IP67K XCSP3919P20
Telemecanique
Telemecanique XCSPL551 Safety Limit Switch
Telemecanique
Telemecanique XMLR010G1N75 Pressure Sensor with Display, 0–10 bar, 0–10 V + 1× NPN
Telemecanique
Telemecanique XZCRB151141C2 Jumper Cable, M12 Male to M12 Female, Shielded, 4-pin, PUR
Technical guides
Catalogue entry last verified: 2026-10-03. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy XCSDMP5902?
- XCSDMP5902 can be ordered from cballast.com as a Telemecanique catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Telemecanique product?
- The manufacturer part number is XCSDMP5902.
- What is the HS code for XCSDMP5902?
- The customs tariff (HS) code for XCSDMP5902 is 8544.42.
- Who manufactures XCSDMP5902?
- XCSDMP5902 is a Telemecanique product in the Safety & Detection range.
- Is a datasheet available for XCSDMP5902?
- Yes — the XCSDMP5902 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for XCSDMP5902?
- The minimum order quantity is 1.
- Is XCSDMP5902 available?
- Yes — XCSDMP5902 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
