Telemecanique XCSDMP5015 Coded Magnetic Safety Switch, 1 NO + 2 NC, with LED
Pricing
Request a quote
We reply within 24 hours
Product Description
Telemecanique XCSDMP5015 coded magnetic safety interlock switch for guard-door monitoring, 1 NO + 2 NC contacts, with LED.
Technical Specifications
- Manufacturer part number (MPN)
- XCSDMP5015
- EAN / GTIN
- 3666916059821
- Sales unit
- pcs
- Package quantity
- 14 pcs
- Contact configuration
- NO + 2 NC
- Type of actuation
- Magnet
- Type of electric connection
- Cable radial
- Type of switching output
- Relay contact
- Width sensor
- 25 mm
- Height of sensor
- 88 mm
- Length of sensor
- 13 mm
- Explosion safety category for gas
- None
- Construction type housing
- Cuboid
- Housing material
- Plastic
- Protected switch distance OFF
- 20 mm
- Protected switch distance ON
- 8 mm
- SIL according to IEC 61508
- 3
- Performance level according to EN ISO 13849-1
- Level e
- Max. output current at protected output
- 100 mA
- Ambient temperature
- -25–85 °C
- Mechanical mounting condition for sensor
- Not flat
- Min. output current
- 100 mA
- Rated supply voltage DC
- 24 V
- Voltage type
- AC/DC
- Cross-/short circuit identification possible
- Yes
- Switching distance
- 20 mm
- With monitoring function downstream switching devices
- No
- Suitable for safety functions
- Yes
- With status indication
- No
- Degree of protection (IP)
- IP67K
- Country of origin
- France
Standards & Compliance
- HS Code
- 8536.50
Cross References
- EAN 3666916059821
- SAP 1000256762
- Code 8229182
Product Documentation
More from Telemecanique
Telemecanique
Telemecanique XY2CEDA290 Emergency Stop Rope Pull Switch, 100 m Rope Span
Telemecanique
Telemecanique XUB0BPSNL2 Multimode Photoelectric Sensor, Metal, PNP, programmable, 2 m cable
Telemecanique
Telemecanique XUSZAML2PTS Muting Arm, L-Shape, for XUSL Safety Light Curtains
Telemecanique
Telemecanique XCMD2106M12 Limit Switch, Cat's Whisker (Spring Rod), Metal Body, M12 connector
Telemecanique
Telemecanique XY2CE4A020 Emergency Stop Rope Pull Switch, 1 NC + 1 NO
Telemecanique
Telemecanique XCSDMP79010 Coded Magnetic Safety Switch, 2 NC, 10 m cable
Telemecanique
Telemecanique XY2CJL19H7 Emergency Stop Rope Pull Switch, 30 m Rope Span, 2 NC + 1 NO, 1/2" NPT entry
Telemecanique
Telemecanique XU9M18MB230 Photoelectric Sensor Ø18 mm, Polarised Reflex, 230 V AC, NC
Technical guides
Catalogue entry last verified: 2026-10-03. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy XCSDMP5015?
- XCSDMP5015 can be ordered from cballast.com as a Telemecanique catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Telemecanique product?
- The manufacturer part number is XCSDMP5015.
- What is the HS code for XCSDMP5015?
- The customs tariff (HS) code for XCSDMP5015 is 8536.50.
- Who manufactures XCSDMP5015?
- XCSDMP5015 is a Telemecanique product in the Safety & Detection range.
- Is a datasheet available for XCSDMP5015?
- Yes — the XCSDMP5015 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for XCSDMP5015?
- The minimum order quantity is 1.
- Is XCSDMP5015 available?
- Yes — XCSDMP5015 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
