Telemecanique XCSDMP79010 Coded Magnetic Safety Switch, 2 NC, 10 m cable
Pricing
Request a quote
We reply within 24 hours
Product Description
Telemecanique XCSDMP79010 coded magnetic safety interlock switch for guard-door monitoring, 2 NC contacts, 10 m cable.
Technical Specifications
- Manufacturer part number (MPN)
- XCSDMP79010
- EAN / GTIN
- 3666916059586
- HS code
- 8544.42
- Sales unit
- pcs
- Package quantity
- 8 pcs
- Contact configuration
- NC + NC
- Type of actuation
- Magnet
- Type of electric connection
- Cable radial
- Type of switching output
- Relay contact
- Width sensor
- 25 mm
- Height of sensor
- 88 mm
- Length of sensor
- 13 mm
- Explosion safety category for gas
- None
- Construction type housing
- Cuboid
- Housing material
- Plastic
- Protected switch distance OFF
- 20 mm
- Protected switch distance ON
- 8 mm
- SIL according to IEC 61508
- 3
- Performance level according to EN ISO 13849-1
- Level e
- Max. output current at protected output
- 100 mA
- Mechanical mounting condition for sensor
- Not flat
- Min. output current
- 100 mA
- Voltage type
- AC/DC
- Cross-/short circuit identification possible
- Yes
- Switching distance
- 20 mm
- With monitoring function downstream switching devices
- No
- Suitable for safety functions
- Yes
- With status indication
- No
- Degree of protection (IP)
- IP67K
- Country of origin
- France
Standards & Compliance
- HS Code
- 8544.42
Cross References
- EAN 3666916059586
- SAP 1000342325
- Code 8999009
Product Documentation
