Telemecanique XCSLF3535512 Safety Switch Guard Locking Metal 24 V 4NO+2NC

Telemecanique XCSLF3535512 is a mechanical safety switch with guard locking in a metal housing, wired for 4 NO + 2 NC contacts at 24 V AC/DC on operating-current principle. It carries an IP67K rating, a 20 N guard-locking force and a metric M20 cable entry, with a rated operating current of 0.75 A at AC-15, 230 V.

Manufacturer part number (MPN)

XCSLF3535512

EAN / GTIN

3666916047705

Sales unit

pcs

Package quantity

8 pcs

Voltage

24 V

Contact configuration

4 NO + 2 NC

Type of locking

Operating current principle

Rated operation current Ie at AC-15, 230 V

0.75 A

Housing material

Metal

Suitable for safety functions

Yes

With status indication

Yes

Type of switching contact

Slow-action switch

Type of interface for safety communication

None

Type of electric connection

Cable entry metrical

Explosion safety category for gas

None

Degree of protection (IP)

IP67K

Type of interface

None

Rated control supply voltage magnet drive AC 50 Hz

24 V

Rated control supply voltage magnet drive AC 60 Hz

24 V

Rated control supply voltage magnet drive DC

24 V

Rated operation current Ie at DC-13, 24 V

0.55 A

Width sensor

44 mm

With escape release

No

Height of sensor

205 mm

Length of sensor

51 mm

Ambient temperature during operating

-25–60 °C

Guard locking force

20 N

Number of contacts as normally closed contact

1

Number of contacts as normally open contact

2

With auxiliary release

No

Type of guard locking

Quiescent current principle

Country of origin

Indonesia

HS Code

8536.50

• EAN 3666916047705
• SAP 1000336183
• Code 8960074
