Telemecanique XCSDMC59110 Coded Magnetic Safety Switch, 1 NO + 1 NC, with LED
Pricing
Request a quote
We reply within 24 hours
Product Description
Telemecanique XCSDMC59110 coded magnetic safety interlock switch for guard-door monitoring, 1 NO + 1 NC contacts, with LED.
Technical Specifications
- Manufacturer part number (MPN)
- XCSDMC59110
- EAN / GTIN
- 3666916060124
- HS code
- 8544.42
- Sales unit
- pcs
- Package quantity
- 10 pcs
- Contact configuration
- NO + NC
- Type of actuation
- Magnet
- Type of electric connection
- Cable radial
- Type of switching output
- Relay contact
- Width sensor
- 16 mm
- Height of sensor
- 51 mm
- Length of sensor
- 7 mm
- Explosion safety category for gas
- None
- Construction type housing
- Cuboid
- Housing material
- Plastic
- Protected switch distance OFF
- 15 mm
- Protected switch distance ON
- 5 mm
- SIL according to IEC 61508
- 3
- Performance level according to EN ISO 13849-1
- Level e
- Max. output current at protected output
- 100 mA
- Mechanical mounting condition for sensor
- Not flat
- Min. output current
- 100 mA
- Voltage type
- AC/DC
- Cross-/short circuit identification possible
- Yes
- Switching distance
- 15 mm
- With monitoring function downstream switching devices
- No
- Suitable for safety functions
- Yes
- With status indication
- No
- Degree of protection (IP)
- IP67K
- Country of origin
- France
Standards & Compliance
- HS Code
- 8544.42
Cross References
- EAN 3666916060124
- SAP 1000342305
- Code 81106738
Product Documentation
More from Telemecanique
Telemecanique
Telemecanique XS1N30PA349L2 Inductive Sensor M30, PNP NO, 10 m Cable
Telemecanique
Telemecanique XZCPV1264L2 Sensor Cable, M12 female angled, 5-pin, PVC, 2 m
Telemecanique
Telemecanique XMLA070D2S12 Pressure Switch, 5–70 bar
Telemecanique
Kab PUR M12SKJ.90°female 4PIN 10M
XZCPB1241L10
Telemecanique
Telemecanique ZCMC29L1 Contact Body for XCM Limit Switches, 1 NO + 1 NC, snap action, 1 m cable
Telemecanique
Telemecanique OsiSense XS912RWPAM12 Inductive Proximity Sensor — M12 stainless barrel, Sn 6 mm, PNP, NO, M12 connector (4-Pin)
Telemecanique
Telemecanique XZCP1670L5 Sensor Cable, M8 female, 3-pin, 5 m
Telemecanique
Telemecanique XCSDMR5902 Coded Magnetic Safety Switch, 1 NO + 1 NC
Technical guides
Catalogue entry last verified: 2026-10-03. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy XCSDMC59110?
- XCSDMC59110 can be ordered from cballast.com as a Telemecanique catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Telemecanique product?
- The manufacturer part number is XCSDMC59110.
- What is the HS code for XCSDMC59110?
- The customs tariff (HS) code for XCSDMC59110 is 8544.42.
- Who manufactures XCSDMC59110?
- XCSDMC59110 is a Telemecanique product in the Safety & Detection range.
- Is a datasheet available for XCSDMC59110?
- Yes — the XCSDMC59110 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for XCSDMC59110?
- The minimum order quantity is 1.
- Is XCSDMC59110 available?
- Yes — XCSDMC59110 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
