Telemecanique XCS solenoid safety interlock switch, 230 V, 4NO+2NC

Telemecanique XCSLE3535342 is a plastic-housed solenoid safety interlock switch with 230 V coil and a 4 NO + 2 NC contact configuration in slow-action design. The switch works on the operating-current principle with a 20 N guard locking force and an M20 metric cable entry. Rated IP67K for use from -25 to +60 °C.

Manufacturer part number (MPN)

XCSLE3535342

EAN / GTIN

3666916047958

Sales unit

pcs

Package quantity

10 pcs

Voltage

230 V

Contact configuration

4 NO + 2 NC

Type of locking

Operating current principle

Rated operation current Ie at AC-15, 230 V

0.75 A

Housing material

Plastic

Suitable for safety functions

Yes

With status indication

Yes

Type of switching contact

Slow-action switch

Type of interface for safety communication

None

Type of electric connection

Cable entry metrical

Explosion safety category for gas

None

Degree of protection (IP)

IP67K

Type of interface

None

Rated control supply voltage magnet drive AC 50 Hz

230 V

Rated control supply voltage magnet drive AC 60 Hz

230 V

Rated control supply voltage magnet drive DC

230 V

Rated operation current Ie at DC-13, 24 V

0.55 A

Width sensor

44 mm

With escape release

No

Height of sensor

205 mm

Length of sensor

51 mm

Ambient temperature during operating

-25–60 °C

Guard locking force

20 N

Number of contacts as normally closed contact

1

Number of contacts as normally open contact

2

With auxiliary release

No

Type of guard locking

Quiescent current principle

Country of origin

Indonesia

HS Code

8536.50

• EAN 3666916047958
• SAP 1000336171
• Code 81085297
