Telemecanique XCSLE2525512 Safety Interlock Switch with Solenoid Locking 24V 2NO+2NC

Telemecanique XCSLE2525512 is a mechanical guard-locking safety interlock switch in a plastic housing with a slow-action contact block configured as 2 NO + 2 NC. It operates on 24 V AC/DC with a metric M20 cable entry and provides IP67K protection with status indication. Rated operating current is 0.75 A at AC-15 230 V and 0.55 A at DC-13 24 V, with a guard-locking force of 20 N and an ambient range of -25 to 60 °C.

Manufacturer part number (MPN)

XCSLE2525512

EAN / GTIN

3666916048054

Sales unit

pcs

Package quantity

8 pcs

Voltage

24 V

Contact configuration

2 NO + 2 NC

Type of locking

Operating current principle

Rated operation current Ie at AC-15, 230 V

0.75 A

Housing material

Plastic

Suitable for safety functions

Yes

With status indication

Yes

Type of switching contact

Slow-action switch

Type of interface for safety communication

None

Type of electric connection

Cable entry metrical

Explosion safety category for gas

None

Degree of protection (IP)

IP67K

Type of interface

None

Rated control supply voltage magnet drive AC 50 Hz

24 V

Rated control supply voltage magnet drive AC 60 Hz

24 V

Rated control supply voltage magnet drive DC

24 V

Rated operation current Ie at DC-13, 24 V

0.55 A

Width sensor

44 mm

With escape release

No

Height of sensor

205 mm

Length of sensor

51 mm

Ambient temperature during operating

-25–60 °C

Guard locking force

20 N

Number of contacts as normally closed contact

1

Number of contacts as normally open contact

1

With auxiliary release

No

Type of guard locking

Quiescent current principle

Country of origin

Indonesia

HS Code

8536.50

• EAN 3666916048054
• SAP 1000336165
• Code 81085279
