Telemecanique XX218A3PHM12 Ultrasonic Sensor, Sn 0.5 m, PNP, M12 connector
Pricing
Request a quote
We reply within 24 hours
Product Description
Telemecanique XX218A3PHM12 OsiSense XX ultrasonic proximity sensor, Sn 0.5 m, PNP output, M12 connector.
Technical Specifications
- Manufacturer part number (MPN)
- XX218A3PHM12
- EAN / GTIN
- 3666916079997
- Sales unit
- pcs
- Package quantity
- 15 pcs
- Diameter
- 18 mm
- Output type
- PNP
- Nominal sensing distance Sn
- 0.5 m
- Voltage type
- AC/DC
- Max. output current
- 100 mA
- Housing material
- Plastic
- Ambient temperature
- -20–65 °C
- Switching frequency
- 300 Hz
- Type of electric connection
- Connector M12
- Type of switching output
- PNP/PNP
- Type of switch function
- Normally open contact (NO)
- Blind zone
- 51 mm
- Setting procedure
- Teach-In
- Explosion safety category for gas
- None
- Construction type housing
- Cylinder, screw-thread
- No-load current
- 40 mA
- Relative linearity deflection
- 0 %
- Relative repeat accuracy
- 1.27 %
- Synchronisation possible
- No
- Supply voltage
- 12–24 V
- Material active area of sensor
- Plastic
- Degree of protection (IP)
- IP67
- Width sensor
- 18 mm
- Diameter sensor
- 18 mm
- Height of sensor
- 18 mm
- Length of sensor
- 79 mm
- Adjustable distance
- 51–508 mm
- Measuring range length
- 51–508 mm
- Country of origin
- United States
Standards & Compliance
- HS Code
- 8536.50
Cross References
- EAN 3666916079997
- SAP 1000001719
- Code 816163
Product Documentation
More from Telemecanique
Telemecanique
Telemecanique XUSL4MA30H106N Type 4 Safety Light Grille with Integrated Muting, 1060 mm protected height
Telemecanique
Telemecanique XUSL4E3BB081NS2 Safety Light Grid Type 4, Body Detection, 3 Beams, 810 mm
Telemecanique
Telemecanique XS118B3NAL2 Inductive Proximity Sensor Ø18 mm, Threaded, NPN NO, 2 m cable
Telemecanique
Telemecanique XMLA001R2S11 Pressure Switch, 03–1 bar
Telemecanique
Telemecanique XMLP100PP230 Pressure Transmitter, 0–100 psi, 0.5–4.5 V ratiometric, 1/4" NPT, Packard connector
Telemecanique
Telemecanique XZCP1662L5 Sensor Cable, M8 female, 3-pin, 5 m
Telemecanique
Telemecanique XU2N18PP341D Photoelectric Through-Beam Set Ø18 mm, Stainless Steel, PNP, M12 Connectors
Telemecanique
Telemecanique XZCP2737L2 Sensor Cable, M8 male straight, 3-pin, 2 m
Technical guides
Catalogue entry last verified: 2026-10-03. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy XX218A3PHM12?
- XX218A3PHM12 can be ordered from cballast.com as a Telemecanique catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Telemecanique product?
- The manufacturer part number is XX218A3PHM12.
- What is the HS code for XX218A3PHM12?
- The customs tariff (HS) code for XX218A3PHM12 is 8536.50.
- Who manufactures XX218A3PHM12?
- XX218A3PHM12 is a Telemecanique product in the Sensors & Instrumentation range.
- Is a datasheet available for XX218A3PHM12?
- Yes — the XX218A3PHM12 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for XX218A3PHM12?
- The minimum order quantity is 1.
- Is XX218A3PHM12 available?
- Yes — XX218A3PHM12 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
